AIRFLOW CONTROL
Airow Options
e magnetic deectors can be used to mount the system lower in the cellar, ush-mount the condenser side of the system,
or direct the airow to avoid recirculation. Simply apply the magnetic deectors in one of the positions displayed below.
Choose the option that will best suit your installation.
NOTE: Do not cover both of the openings on the same side of the unit for any reason.
is will cause cooling issues and premature failure.
NOTE: Do not cover both of the openings on the same side of the unit for any
reason. is will cause cooling issues and premature failure.
ONE-SIDE SELECTIVE AIRFLOW OPTIONS
TWO-SIDE SELECTIVE AIRFLOW OPTIONS
OPTION 1
OPTION 5
OPTION 2
OPTION 6
OPTION 3
OPTION 7
OPTION 4
OPTION 8
