7-22 Wiring Diagrams (General)
Magnum 4A Control Wiring and Adjustment Manual www.NabcoEntrances.com
Part #C-00084 Rev. 9-09-16
DN 0552D
DN0052
O
F
F
12
4
3
AUX
PWR
J2
J5
AC IN
F2
SW2
SW1
F1
R2
R3
R4
R5
R6
R7
R8
TDAS TDPG LCHK CLOSESTOP OPEN BCHK
CURRENT
LIMIT
MOTOR
J1
R28
MAGNUM 4A
LED
TRANSFORMER
RELAY
RELAY
J4
SIGNAL
INPUT
CAPACITOR
C26
D10
MOV3
ORANGE
VIOLET
WHITE
RED
BLACK
BROWN
6
5
4
3
2
1
MAGNUM CONTROL BOARD
BLACK
RED
PART # 22-10065
MAIN HARNESS
BLACK
BLACK
BLACK
GREEN
WHITE
120 VAC "HOT"
120 V
"
SER
AMPERE SERVICE
PER OPERATOR
BLACK
GROUND
RED
WHITE
BLACK
TO TERMINAL #5
TO TERMINAL #5
GREEN
RED & BLACK
FOR RIGHT HAND OPERATORS,
MATCH MOTOR WIRES,
RED TO RED, BLACK TO BLACK.
FOR LEFT HAND OPERATORS,
MIS-MATCH THE MOTOR WIRES,
RED TO BLACK, BLACK TO RED.
ACTIVATION
(OUTPUT FROM SENSOR, REMOTE
RECEIVER, PUSH PLATE, ETC.)
SAFETY WITH LOCKOUT
(OUTPUT FROM OVERHEAD
SWING-SIDE SENSOR)
CONTINUOUS SAFETY
(OUTPUT FROM DOOR MOUNTED
SWING-SIDE SENSOR)
MOTOR FUSE
P. N. 11-1236
FOR 710 ONLY
ON/OFF
ROCKER
SWITCH
P. N. 11-13185
TERMINAL BLOCK
K
24VAC NEUTRAL
24VAC HOT
CONTINUOUS SAFETY
SAFETY WITH LOCKOUT
24VAC COMMON
ACTIVATION
Off
Hold Open
On
Off
Part # 10-3528
RS-12 Rocker Switch
To Next Page
