Magnum 4A Control Wiring and Adjustment Manual www.NabcoEntrances.com
Part #C-00084 Rev. 9-09-16
2-6 Geng Started
Table 2-3 Power Wiring
Wiring Power Current Consumption
Maximum Input 500mA (0.5amps)
Output (Available for Accessories) 500mA (0.5amps)
Available Wire Size for Incoming Power 14 AWG -
-
-
Fuses -
-
► Sensors
► Modules
► Accessories
► Auxiliary Equipment
If current draw exceeds 500 mA (0.5 amps) the installer must utilize an auxiliary power supply
such as the
The Opus 10 Control must Not be used to output power to:
► Magnetic Locks
► Electric Strikes
To determine if an auxiliary power supply must be used, add the total current draw of all devices. Please
50 mA
An Auxiliary Power Supply does not need to be used.
