NAD 402 - Page 17

a a
SYMBOL NO. PART NUMBER DESCRIPTION | REMARKS
C22 150F103K-5-UU | Capacitor Ceramic 0.01uF +10% 50V
C23 150F103Z-5-I! Capacitor Ceramic 0.01uF +80-20% 50V
C24 150F 103K-5-UU Capacitor Ceramic 0.01uF +10% 50V
C25 150F103Z-5-l! Capacitor Ceramic 0.01uF +80-20% 50V
C26 N15510210-M Capacitor Trimmer, 6mm, TZ03R300FR = 30pF
C27 150F103K-5-UU Capacitor Ceramic 0.01uF +10% 50V
C28 15CH220J-5-GG Capacitor Ceramic 22pF NPO +5%
C29 158E471J-5-IQ Capacitor Polystyrene 470pF +5% 25V
C30 157F475M-5-IU Capacitor — Electrolytic 4.7uF +20% 50V
C31 150F473Z-5-SG Capacitor Ceramic 0.047uF +80-20% 50V
C32 157D106M-5-IU Capacitor — Electrolytic 10uF +20% 16V
C33 150F 103Z-5-Il Capacitor Ceramic 0.01uF +80-20% 50V
C34, C35 150F473Z-5-SG Capacitor Ceramic 0.047uF +80-20% 50V
C36, C37 150F101J-5-IF Capacitor Ceramic 100pF 45% 50V
C38 150F103Z-5-ll Capacitor Ceramic 0.01uF +80-20% 50V
C39 157D107Z-5-KW Capacitor — Electrolytic 100uF +80-20% 16V
C40 158D101J-5-1Q Capacitor Polystyrene 100pF t5% 16V
C41 157F335M-5-1U Capacitor — Electrolytic 3.3uF +20% 50V
C42
150F103Z-5-ll
Capacitor
Ceramic
0.01uF
+80-20%
50V
C43
157F335M-5-IU
Capacitor
Electrolytic
3.3uF
+20%
50V
C44 150F473Z-5-SG Capacitor Ceramic 0.047uF +80-20% 50V
C45 15CH470J-5-KG Capacitor Ceramic 47pF NPO +5%
C46,
C47
150F473Z-5-SG
Capacitor
Ceramic
0.047uF
+80-20%
50V
C48
150F1032Z-5-II
Capacitor
Ceramic
0.01uF
+80-20%
50V
C49
157D1072-5-KW
Capacitor
—
Electrolytic
100uF
+80-20%
16V
C50
157F105M-5-1U
Capacitor
—
Electrolytic
1uF
+20%
50V
C51
157F224M-5-IU
Capacitor
Electrolytic
0.22uF
+20%
50V
C52,
C53
157F105M-5-IU
Capacitor
—
Electrolytic
tuF
+20%
50V
C54
150F473M-5-SG
Capacitor
Ceramic
0.047uF
+20%
50V
C55 157F104M-5-IU Capacitor — Electrolytic 0.1uF +20% 50V
C56
157D106M-5-IU
Capacitor
—
Electrolytic
10uF
+20%
16V
C57
150F391K-5-RF
Capacitor
Ceramic
390pF
+10%
50V
C58
157D476M-5-IU
Capacitor
Electrolytic
47uF
+20%
16V
C59
157D106M-5-IU
Capacitor
—
Electrolytic
10uF
420%
16V
C60
157D107Z-5-KW
Capacitor
—
Electrolytic
100uF
+80-20%
16V
C61,
C62
450F1032-5-1
Capacitor
Ceramic
0.01uF
+80-20%
50V
C63,
C64
150F1032Z-5-Il
Capacitor
Ceramic
0.01uF
+80-20%
50V
C65
157E4772Z-5-S5
Capacitor
—
Electrolytic
470uF
+80-20%
25V
C66
150F104Z-5-IU
Capacitor
Ceramic
0.1uF
+80-20%
50V
C67,
C68
1571337Z-5-Y9
Capacitor
—
Electrolytic
330uF
+80-20%
63V
Cé9
157F106Z-5-IU
Capacitor
—
Electrolytic
10uF
+80-20%
50V
C70,
C71
157E2282-5-6@
Capacitor
—
Electrolytic
2200uUF
+80-20%
25V
C72,
C73
150F1042-5-IU
Capacitor
©
Ceramic
0.4uF
+80-20%
50V
C74
157E1062-5-IU
Capacitor
—
Electrolytic
10uF
+80-20%
25V
C75
150F1042Z-5-IU
Capacitor
Ceramic
0.1uF
+80-20%
50V
C401,
C402*C
158E421J-5-IQ
Capacitor
Polystyrene
420pF
15%
25V
C401,
C402
*
AH
158E911J-5-IQ
Capacitor
—
Polystyrene
910pF
15%
25V
C403,
6404
153F152K-5-KW
Capacitor
Mylar
1500pF
+10%
50V
C405,
C406
157F475M-5-IU
Capacitor
Electrolytic
4.7uF
+20%
50V
C407,
C408
157F475M-5-1U
Capacitor
—
Electrolytic
4.7uF
+20%
50V
Di,
D2
N4801N60P-1
Diode
Germanium
2-1K60
D3,
D4
N484C321D-5
Diode
AFC
SVC321SPA
D5,
D6
4804
1480-2
Diode
1N4148
D7 4804 1480-2 Diode 1N4148
D8,
D9
48040010-2
Diode
1N4001
D10
N48400490-0
Rectifier
Bridge
RBi52
100V
1.5A
Dit,
Di2
48040010-2
Diode
1N4001
D13
483733V1-2
Diode
Zener
33V
1/2W
