NAD 917 - Recalling Preset Stations

will
be
shown
in
the
panel
display.
Use
the
AV
buttons
to
select
which
preset
number
you
wish
to
assign
to
the
station
and
then
press
STORE
again.
This
will
store
the
frequency
into
the
preset
number
being
currently
displayed.
You
can
assign
any
station
to
any
of
the
19
presets
in
any
order
you
wish.
The search function will slow down when weak trans-
missions are registered. To stop the Search function
at any of these stations press the MODE button.
Press A or W to restart Search.
FINDING AND STORING AM & FM STATIONS
USING MANUAL TUNE.
You can also manually TUNE stations and STORE
them into the unit's memory.
First select the AM or the FM band using the AM FM
button. Press MODE until the P points to TUNE in
the Display Panel. Pressing the A button steps up
the frequency band and pressing W steps down the
frequency band. The Tune Assist indicators > <4 wit
illuminate when you are close to correctly tuning into
the station and perfect tuning is indicated by the sta-
tion lock indicator ®. If you wish to store that station
as a preset, press STORE once and the current pre-
set number will be shown in the Display Panel. Use
the & Y buttons to select which preset number you
wish to assign to the station and then press STORE
again. This will store the station’s frequency into the
preset number being currently displayed. You can
assign any station to any of the 19 presets in any
order you wish.
RECALLING PRESET STATIONS.
To recall any of the preset stations select the required
band using the AM FM button and then press MODE
until the P» points to PRESET on the Display Panel.
Press the & or V buttons to page up or down to the
required Preset.
DOLBY PRO LOGIC AND SOUND SPACE
(See also: Remote Control)
The Dolby Pro Logic and Sound Space buttons
switches the 917 from stereo operation (Front Left
and Right speakers only) to one of two types of sur-
round mode:
The Sound Space modes are used to enhance stereo
source material and the Dolby Pro Logic mode is
used to play back Dolby Surround encoded movies,
programmes and CDs.
15. DOLBY PRO LOGIC
The DOLBY PRO LOGIC button switches the 917
into Dolby Pro Logic mode. The Dolby Pro Logic
decoder circuit will work with all inputs except for
MONITOR 1 & 2, but will only function properly with
material encoded in Dolby Surround. The button indi-
cator illuminates when this mode has been selected.
GB)
16. DELAY
Press DELAY to set the overall delay time applied to
the Surround channels to 15ms, 20ms, 25ms or
30ms. The delay time will be shown in the display
panel for a few seconds after the DELAY button has
been pressed. (See also: Setting The Surround
Delay)
17. SOUND SPACE
The three Sound Space modes can be used to create
a surround sound image from a stereo signal. The
Sound Space circuits will work with ail inputs except
for MONITOR 1 & 2. The button indicator illuminates
when each mode is selected.
CLUB: Press CLUB to re-create the sound of a small
venue. This is more suitable for recordings of
soloists, small ensembles and jazz.
HALL: Press HALL to create the sound of a larger
concert hall. Try the HALL setting for larger orchestral
works and rock.
STADIUM: Press STADIUM to re-create the sound of
a large stadium. The STADIUM setting can be used
for rock and pop and the largest orchestral works.
18. SIBILANCE FILTER
The tonal balance of some Laser Disc sound tracks
can sound over-bright which leads to sibilance on
speech (a hissing of splashy sound on consonants).
The SIBILANCE FILTER reduces the extreme high
frequency content, restoring a satisfactory tonal bal-
ance. The button indicator illuminates when the SIBI-
LANCE FILTER is active. The filter only functions
when the 917 is in Dolby Pro Logic or Sound Space
Modes.
19. CDR
The 917 features the CONTROLLED DYNAMIC
RANGE (CDR) circuit, which is used for listening at
lower levels. This is a sophisticated dynamics con-
troller that selectively raises the level of the quieter
parts of the soundtrack, whilst leaving the louder
parts unaltered.
Using CDR at lower listening levels (eg late at night),
the apparent dynamics of the soundtrack can be
maintained, without the dialogue becoming too quiet
to hear comfortably.
The button indicator illuminates when CDR is active.
CDR only functions when the 917 is in Dolby Pro
Logic or Sound Space modes.
SETTING UP THE SURROUND SYSTEM.
To work at its best, the output levels of the 917’s sur-
round facilities need to be adjusted so that there is an
even balance of sound from all the speakers in the
system. The Delay time for the Surround speakers
‘Date: SURROUND _ SUB WOOFER CENTER DELAY (ms)
SETTING +
“Date. ~~: DOLBY 3CH/4CH PHANTOM/ NORMAL SUB WOOFER
_SETTING
