NAD T 741 - Jacks; Sockets and Connectors

58
AUDIO
ASSEMBLY
3000 PCB-N0A00C-AUD AUDIO ASSEMBLY
CAPACITORS
C301-C306 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C309-C314 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C315, C316 150F-103K-2-FC CC 50V 0.01μF 10% AT 3.5
C317, C318 150F-223K-2-FD CC 50V 0.022μF 10% AT
C319-C324 157D-335M-5-II CE 16V 3.3μF 20% RL 5x5
C325, C326 157D-107M-5-IU CE 16V 100μF 20% RL 5x11
C327, C328 157D-476M-5-IU CE 16V 47μF 20% RL 5x11
SOCKETS / JACKS
J709B, J710B 2101-1801-0 SOCKET (PCB/PCB) 10P
M301, M302 2113-1677-0 6P RCA JACK R/W NI
TRANSISTOR
Q301 485C-144E-5 TR DTC144ES ROHM
RESISTORS
R329-R331 4701-102J-C RCF 1/8W 1K 5% ATS
R303, R304, R306, R308 4701-105J-C RCF 1/8W 1M 5% ATS
R310, R312, R319, R320 4701-105J-C RCF 1/8W 1M 5% ATS
R323, R324, R327, R328 4701-105J-C RCF 1/8W 1M 5% ATS
R309, R311, R315, R316 4701-222J-C RCF 1/8W 2.2K 5% ATS
R321, R322, R325, R326 4701-222J-C RCF 1/8W 2.2K 5% ATS
R301, R302, R305, R307 4701-331J-C RCF 1/8W 330R 5% ATS
ICs
U301 3130-3870-0 IC HCF4053BT
U302 3131-3570-0 IC TC9273N-004 ANALOG
ZENERS
Z301, Z302 4837-7B51-2 DZ 1/2W 7.07~7.45V ROHM
DIG ASSEMBLY
1200 PCB-N0A00C-DIG DIG ASSEMBLY
JACKS
J101B 2102-101S-004 WAFER 10P P2.5 ST.
1063, 1064 2113-1311-0 1P RCA JACK BK NI
1065 2113-1777-0 JACK RCA 2P YL NICKEL-
RECEIVER
1062 4811-F32R-3 LIGHT RX UNIT GPIF32R
CAPACITORS
C763, C764 150F-104K-2-FC CC 50V 0.1μF 10% AT
C765, C766 150F-223K-2-FD CC 50V 0.022μF 10% AT
DIODES
D756-D759 4804-1480-C DIODE 1N4148 ATS
RESISTORS
R759, R760 4701-102J-C RCF 1/8W 1K 5% ATS
R761 4701-101J-C RCF 1/8W 100R 5% ATS
Reference No.
Part No. Description
