NAD T 741 - Page 47

59
R762 4701-104J-C RCF 1/8W 100K 5% ATS
IC
U761 3130-7370-0 IC 74HCT00 NAND GATE
KEY
ASSEMBLY
2200 PCB-N0A00C-KEY KEY ASSEMBLY
LED DISPLAY
2119 2460-1890-2 VFD 12-MT-84GNK FUTABA
CAPACITORS
C205, C207 150F-104Z-5-IU CC 50V 0.1μF +80/-20% RL
C203, C204 150F-220K-5-GG CC 50V 22pF 10% RL 4x4
C201 157B-107M-5-KM CE 6.3V 100μF 20% RL 6x7
C206 157B-227M-5-KW CE 6.3V 220μF 20% RL
C208, C210, C212 157D-476M-5-IU CE 16V 47μF 20% RL 5x11
C209 157E-335M-5-GM CE 25V 3.3μF 20% RL 4x7
C202 150F-103K-2-FC CC 50V 0.01μF 10% AT 3.5
DIODES
D212 4804-0010-2 DIODE 1N4001 AT
D201,D202,D205 4804-1480-C DIODE 1N4148 ATS
D206,D209,D210,D213 4804-1480-C DIODE 1N4148 ATS
ZENER
D214 4837-4C20-2 DZ 1/2W 5.0-5.2V AT
D203, D211 4837-5B61-2 DZ 1/2W 5.45-5.73 ROHM
FLEXIBLEs
J203A, J206A 2101-1581-0 FLEXIBLE CONN. 35P
WIRE CON ASSY
J208B 7702-1120-2004 WIRE CON ASSY 2P P=2.5
J207A 7703-1150-2004 WIRE CON ASSY 3P P=2.5
J202A 7704-1200-2004 CN ASSY 4P P=2.5 L=200
J201A 7705-1410-2004 CONN ASSY 5P P2.5 L=410
COIL
L201 1801-220K-M COIL 22μH 10% AL BL7
MISCELLANEOUS
M218 2954-3008-0000 TAPPING 3X8MM B-TITE
M218 4132-1061-0 SOLDER TAG
2118 4152-5741-0 HOLDER (FL)
CRYSTAL
M219 2300-3150-0 CRYSTAL 10MHZ +/-30PPM
SWITCHES
M201-M217, M222 5200-3538-0 SWITCH, TACT SKHHBY 7MM
TRANSISTOR
M218 4814-3TE2-3 IR SENSOR PIC-12043TE2
Q203 485C-114E-5 TR DTC114ES
Q202 485C-144E-5 TR DTC144ES ROHM
Reference No.
Part No. Description
