NAD T 741 - Page 58

70
R944 4701-104J-C RCF 1/8W 100K 5% ATS
R945 4701-392J-C RCF 1/8W 3.9K 5% ATS
R946 4701-332J-C RCF 1/8W 3.3K 5% ATS
R947,R948 4701-103J-C RCF 1/8W 10K 5% ATS
R949 4701-332J-C RCF 1/8W 3.3K 5% ATS
R950 4701-684J-C RCF 1/8W 680K 5% ATS
R951 4701-102J-C RCF 1/8W 1K 5% ATS
R952,R953 4701-223J-C RCF 1/8W 22K 5% ATS
R954 4701-103J-C RCF 1/8W 10K 5% ATS
R955 4701-220J-C RCF 1/8W 22R 5% ATS
R957,R958 4701-332J-C RCF 1/8W 3.3K 5% ATS
R959,R960 4701-683J-C RCF 1/8W 68K 5% ATS
R959,R960 4701-334J-C RCF 1/8W 330K 5% ATS
R961,R962 4701-222J-C RCF 1/8W 2.2K 5% ATS
R963,R964 4701-104J-C RCF 1/8W 100K 5% ATS
R968 4701-102J-C RCF 1/8W 1K 5% ATS
R971 4701-000J-2 RCF 1/8W 0R 5% AT
R972 4701-103J-C RCF 1/8W 10K 5% ATS
R973 4701-183J-C RCF 1/8W 18K 5% ATS
R974 4701-104J-C RCF 1/8W 100K 5% ATS
R975 4701-333J-C RCF 1/8W 33K 5% ATS
R975 4701-563J-C RCF 1/8W 56K 5% ATS
R985-R987 4701-102J-C RCF 1/8W 1K 5% ATS
R991 4701-000J-2 RCF 1/8W 0R 5% AT
VOLUMES
R956 4756-1036-3-06 SVR 10K H3 7X7.6 RH0615C
R941 4756-2236-3-06 SVR 22K H3 7X7.6 RH0615C
ICs
U901 3130-8180-0 IC LA1837 AM/FM IF
U903 3131-3760-0 IC LC7218 PLL FREQ
U902 3131-9040-0 IC LC72723M RDS
VIDEO
ASSEMBLY
PCB-N0A00C-VD VIDEO ASSEMBLY
CAPACITORS
C401-C405 157D-107M-5-KW CE 16V 100μF 20% RL 6x12
C406, C407, C409 157D-476M-5-IM CE 16V 47μF 20% RL 5X7
C408, C411 157D-477M-5-SY CE 16V 470μF 20% RL
C410 157D-476M-5-IM CE 16V 47μF 20% RL 5X7
C412 157D-108M-5-S5 CE 16V 1000μF 20% RL
DIODES
D401,D402 4804-1480-C DIODE 1N4148 ATS
SOCKETS / JACKS
J714B 2101-1801-0 SOCKET (PCB/PCB) 10P
M403 2113-1316-0 1P RCA JACK YL NI
M402 2113-1775-0 JACK RCA 2P TL NICKEL-
M401 2113-1776-0 JACK RCA 4P YL NICKEL-
TRANSISTORS
Q401-Q403 485C-114E-5 TR DTC114ES
Q404-Q406 485A-933S-5 TR 2SA933S HFE 120-560
Reference No.
Part No. Description
