NAD T 741 - Page 59

71
Q407,Q410 4860-0770-5 TR 2SC2878 (A,B) RL
Q408,Q409,Q411,Q412 485C-114E-5 TR DTC114ES
RESISTORS
R402 4701-102J-C RCF 1/8W 1K 5% ATS
R403,R404 4701-222J-C RCF 1/8W 2.2K 5% ATS
R405-R408 4701-103J-C RCF 1/8W 10K 5% ATS
R409 4701-203J-C RCF 1/8W 20K 5% ATS
R410 4701-151J-C RCF 1/8W 150R 5% ATS
R411-R413 4701-203J-C RCF 1/8W 20K 5% ATS
R414 4701-151J-C RCF 1/8W 150R 5% ATS
R415,R416 4701-203J-C RCF 1/8W 20K 5% ATS
R417 4701-151J-C RCF 1/8W 150R 5% ATS
R419,R421 4701-102J-C RCF 1/8W 1K 5% ATS
R424-R427 4701-820J-C RCF 1/8W 82R 5% ATS
R428,R429 4701-222J-C RCF 1/8W 2.2K 5% ATS
IC
U401 3131-4100-0 IC MC14051BCP MOTOROLA
ZENERS
Z401,Z402 4837-7C51-2 DZ 1/2W 7.29~7.67V ROHM
VOLUME
ASSEMBLY
PCB-N0A00C-VOL VOLUME ASSEMBLY
WAFER
J207B 2102-031R-004 WAFER 3P P2.5 RIGHT
VOLUME
M301 4750-6000-0 ROTARY ENCODER
Reference No.
Part No. Description
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
- Capacitors : CP-Polystyrene, CM-Mylar, CE-Electrolytic, CC-Ceramic, CTC-NPO.
- Resistors : RMF-Metal Film, RCF-Carbon Film, RWR-Wirewound Metal Oxide.
