NAD T 743 Service Manual

9
WIRING DIAGRAM PARTS LIST
Item Database Part Number Description Remark
1 276-031823-06 CABLE ASSY 3 WAYS AWG=18 3.96P UL1007 AMP1
L=180mm BD-J504A
2 276-051823-19 CABLE ASSY 5 WAYS P3.96 AWG18 UL1007 AMP1
L=200mm BD-J501A
3 276-122413-02 CABLE ASSY 12 WAYS AWG=26 2.5P UL2877 AMP1
L=120mm BD-J503A
4 276-031823-06 CABLE ASSY 3 WAYS AWG=18 3.96P UL1007 AMP2
L=180mm BD-J781B
5 276-042613-08 CABLE ASSY 4 WAYS AWG26 2.5P UL1533 AUDIO
L=450MM (ROHS) BD-J3103A
6 276-022613-07 CABLE ASSY 2 WAYS AWG=26 2.5P UL1533 DIGIT BD-
L=540mm (ROHS) J1009A
7 276-032613-10 CABLE ASSY 3 WAYS AWG=26 X2C P=2.5 DIGITAL BD-
UL2854 L=110mm C33110 (RoHS) J705A
8 276-042613-11 CABLE ASSY 4 WAYS AWG=26 2.5P DIGITAL BD-
UL2877 L=500mm (RoHS) J1010A
9 276-011843-01 CABLE ASSY 1 WAY AWG18 UL1007 BLACK KEYBOARD-
L=100mm W/ RING TERMINAL (RoHS) J201
10 276-052613-08 CABLE ASSY 5 WAYS AWG26 2.5P UL1007 LED BD-
L=160mm (RoHS) J204A
11 276-032613-18 CABLE ASSY 3 WAYS AWG=26 2.5P L=110mm MAIN BD-
J606B
12 276-032613-29 CABLE ASSY 3 WAYS AWG26X2C UL2547 MAIN BD-
L=210mm (UL LABEL) (RoHS) J715A
13 276-082613-22 CABLE ASSY 8 WAYS AWG=26X3C L=480mm MAIN BD-
(RoHS) J709A
14 276-122613-16 CABLE ASSY 12 WAYS AWG26 2.5P UL2468 MAIN BD-
L=230mm (UL LABEL) (RoHS) J502A
15 276-142613-03 CABLE ASSY 14 WAYS AWG=26 2.5P UL1007 MAIN BD-
L=440mm (UL LABEL) (RoHS) J782B
16 276-032613-15 CABLE ASSY 3 WAYS AWG=26 2.5P UL2854 PO BD-
L=420mm (RoHS) J611A
17 276-062613-05 CABEL ASSY 6 WAYS AWG=26 2.5P PO BD-
UL1533X1C L=350mm (RoHS) J612A
18 276-042613-07 CABLE ASSY 4 WAYS AWG26 2.5P UL2468 PS BD-
L=400mm (ROHS) J753A
19 276-031823-04 CABLE ASSY 3 WAYS AWG=18 3.96P UL1007 SPK
L=120mm BD-J801B
20 276-031823-09 CABLE ASSY 3 WAYS AWG=18 3.96P UL1015 SPK BD-
L=320mm J505B
21 276-051823-03 CABLE ASSY 5 WAYS AWG=18 3.96P UL1007 SPK BD-
L=350mm J786B
22 276-051823-26 CABLE ASSY 5 WAYS AWG18 UL1007 SPK BD-
L=300mm (V/B/Y) (UL LABEL) (RoHS) J506B
23 276-082613-20 CABLE ASSY 8 WAYS AWG=26 2.5P UL1007 SV BD-
L=380mm (RoHS) J414A
24 276-082613-27 CABLE ASSY 8 WAYS AWG=26 2.5P UL1007 TR BD-
L=540mm (UL LABEL) (RoHS) J350A
25 276-011843-01 CABLE ASSY 1 WAY AWG18 UL1007 BLACK V6 BD-
L=100mm W/ RING TERMINAL (RoHS) P4401,P4402
26 276-011643-29 CABLE ASSY 1 WAY AWG=16 UL1672 J759
BROWN L=100mm
27 276-011643-69 CABLE ASSY 1 WAY AWG=16 UL1672 J758
BLUE L=100mm
28 238-030070-20 FFC CABLE 30 PINS P1.25 L=70mm J601A
W/SHIELD
