EXPLODED VIEW PARTS LIST
ITEM PART NO. DESC. QTY
1 08-002-0067-90 FAN DC 60x20mm 12V 0.18A 3800RPM DF126020SL 3
L=430mm w/ 2.5P CONNECTOR (RoHS)
2 10-005-0286-90 TRANSFORMER PW EI-114 120V T755 T08789A 1
(RoHS) [FOR 120V VERSION]
10-005-0287-90 TRANSFORMER PW EI-114 230V T755 T08789B 1
(RoHS) [FOR 230V VERSION]
3 11-001-0062-90 SWITCH ROCKER 1P1T BLK/BLK 10A/250VAC 1
TV-5 UL/CSA/VDE/SEMKO (RoHS)
4 15-004-0074-90 AC SOCKET IEC 10A 250V JR-101 (RoHS) 1
[FOR 120V VERSION]
15-004-0075-90 AC INLET 10A 250V R-301 RICH BAY 1
UL/CCC/VDE/N/S (RoHS) [FOR 230V VERSION]
5 15-004-0078-90 AC OUTLET 3 PINS US POLARIZED SS-6B-1-NY 1
(RoHS) [FOR 120V VERSION]
15-004-0076-90 AC OUTLET EURO CEE 7 2.5A/250V A302D0060P 1
(RoHS) [FOR 230V VERSION]
6 15-016-0001-90 AM/FM TUNER MIDULE KST-MB114MA0-23 (RoHS) 1
7 19-001-0116-90 HEATSINK PLATE TRANSISTOR 2.5MM ALUMINIUM 5
(RoHS)
8 19-001-0124-90 EXT. HTSK FRONT T755 (RoHS) 1
9 19-001-0125-90 EXT. HTSK REAR T755 (RoHS) 1
10 21-001-0030-90 NEW VOLUME KNOB ASSY T175 GRAPHITE (RoHS) 1
[FOR GRAPHITE VERSION]
21-001-0031-90 NEW VOLUME KNOB ASSY T175 TITANIUM (RoHS) 1
[FOR TITANIUM VERSION]
11 21-002-0155-90 POWER BUTTON TACT ACTIVE T765 GRAPHITE 1
(RoHS) [FOR GRAPHITE VERSION]
21-002-0156-90 POWER BUTTON TACT ACTIVE T765 TITANIUM 1
(RoHS) [FOR TITANIUM VERSION]
12 21-002-0157-90 2X BUTTON SET T765 GRAPHITE (RoHS) 2
[FOR GRAPHITE VERSION]
21-002-0158-90 2X BUTTON SET T765 TITANIUM (RoHS) 2
[FOR TITANIUM VERSION]
13 21-002-0159-90 4 WAYS BUTTON T765 GRAPHITE (RoHS) 1
[FOR GRAPHITE VERSION]
21-002-0160-90 4 WAYS BUTTON T765 TITANIUM (RoHS) 1
[FOR TITANIUM VERSION]
14 21-002-0161-90 CENTER BUTTON T765 GRAPHITE (RoHS) 1
[FOR GRAPHITE VERSION]
21-002-0162-90 CENTER BUTTON T765 TITANIUM (RoHS) 1
[FOR TITANIUM VERSION]
15 22-001-0367-00 SCREW MACHINE M3 x 6 P/H NI PLT (RoHS) 18
16 22-001-0376-90 MACHINE SCREW M3 x 6 P/H BLK (RoHS) 4
17 22-001-0379-90 MACHINE SCREW M4 x 8 WASHER HEAD BLK 6
(RoHS)
18 22-001-0380-90 HEX HEAD SCREW M5 X 12 NI PLT 4
19 22-001-0381-90 MACHINE SCREW M3 x 10 PAN HEAD NI PLT (RoHS) 6
20 22-001-0384-90 MACHINE SCREW M4 x 14 WASHER HEAD BLK 1
(RoHS)
21 22-001-0409-90 SCREW MACHINE M3 x 15 WASHER HEAD 12
W/ STOPPER NI PLT (RoHS)
22 22-001-0410-90 SCREW MACHINE M2.6 X 6 K/H BLK PLT (RoHS) 3
23 22-003-0030-00 TAPTITE SCREW 3x8 P/H TYPE “B” ZN/NI PLT (RoHS) 47
