NAD T744 - Exploded View Parts List

51
EXPLODED VIEW PARTS LIST
Item Database Part Number Description Qty
1 08-002-0042-00 FAN DC 80 X 80 X 25 12V 0.15A 2700rpm DF128025BB W/360mm 1
2 10-005-0187-90 XFORMER PW EI-96 115V/230V T744 T96-0313002-21 ISSUE 6 1
3 11-001-0061-90
POWER SWITCH TV-8 10A/250VAC UL/CSA/VDE/F/D/S PS3-
22SPA-P7CZ BABY BLUE HN
1
4 17-004-0009-90
POWER CORD UL/CSA 125V VDE LF L=6'7" LP-5W NISPT-2
AWG18 2C 2T [FOR 120V VER.]
1
17-004-0014-90
POWER CORD 250V EURO-PLUG 2.5A/250V VDE L=6'11" LP-21
H03 VVH2-F 2C 2T [FOR 230V VER.]
1
5 17-016-0078-90 JUMPER PLUG PITCH 14mm 3
6 15-004-0079-90 AC OUTLET US POLARIZED SS-6C [FOR 120V VER.] 1
15-004-0076-90 AC OUTLET EURO CEE 7 2.5A/250V A302D0060P [FOR 230
V
1
7 25-020-0338-00 SILICONE RUBBER INSULATOR L18 X W13 X T0.3 W/HOLE 5
8 25-020-0347-90 INSULATOR TO-3P MICA 1.5KV 22 X 27 X 0.125 SK023
A
10
9 15-016-0001-90 AM/FM TUNER MODULE KST-MB114MA0-23 [FOR 120V VER.] 1
15-016-0002-90 AM/FM TUNER MODULE KST-MB114MA1-23 [FOR 230V VER.]
10 22-003-0138-90 SELF TAPPING SCREW 2X5 WASHER HEAD TYPE "B" NI PLT 8
11 22-003-0139-90 SELF TAPPING SCREW DIA2.6 X 5 P/H TYPE "A" NI PLT 2
12 22-003-0126-00 SELF TAPPING SCREW DIA2.6 X 6 P/H TYPE "A" NI PLT 6
13 22-003-0145-90 SELF TAPPING SCREW DIA2.6 X 8 B/H TYPE "A" NI PLT 16
14 25-017-0269-90 BUSHING SQ 11.5 X 16 1.6mm THK. BLK NYLON SB4F-4 1
15 25-014-0030-90 RUBBER FOOT I/D14 X O/D26 X 3 PORON HH-48C 4
16 22-007-0082-90 NUT M5X3.4 NI PLT 4
17 22-007-0083-90 NUT ZINC PLATED M9.0 X 2.2mm 11p 1
18 22-001-0367-00 MACHINE SCREW M3 X 6 P/H NI PLT 23
19 22-001-0376-90 MACHINE SCREW M3 X 6 P/H BLK 4
20 22-003-0149-90 MACHINE SCREW M3.0 X 6.0 B/H TAP TYPE NICKEL PLT 12
21 22-003-0141-90 TAPTITE SCREW 3 X 6 B/H TYPE "B" BLK 4
22 22-003-0030-00 SELF TAPPING SCREW DIA3 X 8 B/B ZINC PLATED TAPTITE- 38
23 22-003-0049-00 TAPTITE SCREW DIA3 X 8 B/H TYPE "B" BLK PLT 39
24 22-003-0143-90 TAPTITE SCREW DIA3 X 10 P/H TYPE "B" BLK 6
25 22-001-0378-90 MACHINE SCREW M3 X 10 B/H BLK 4
26 22-001-0372-00 MACHINE SCREW M3 X 12 B/H NI-PLT 15
27 22-003-0144-90 TAPTITE SCREW 3.5 X 8.0 B/H TYPE "B" NI PLT 5
28 22-001-0379-90 MACHINE SCREW M4 X 8 WASHER HEAD BLK 6
29 22-001-0380-90 HEX HEAD SCREW M5 X 12 NI PLT 4
30 25-006-0043-90 PCB SUPPORTER "KSS" (H=9.6mm PCB HOLE 4mm) CS-0610 3
31 22-008-0024-00 INTERNAL TOOTH WASHER M3 X 0.4mm 4
32 22-005-0032-00 WASHER SPRING I/D 3.2 X O/D 5.6 0.9mm THK 15
33 22-006-0081-00 WASHER STEEL I/D 3.5 X O/D 8.0 0.4mm THK. ZINC PLT. 4
34 22-005-0036-90 WASHER SPRING I/D 5.2 X O/D 8 X 1.2 THK ZINC PLT. 4
35 22-006-0085-90 WASHER STEEL I/D 5.6 X O/D 12 X 1 THK. NI PLT. 8
36 25-020-0348-90 FIBRE INSULATOR 1
37 25-016-0025-90 FOAM 9 X 240 X 1.5mm BLACK (UL GRADE) W/NITTO 500 1
38 25-016-0026-90 FOAM 30x25x6mm 1
39 25-020-0349-90 FIBRE PAPER 60X26X0.8mm 1
40 25-022-1238-90 METAL SPACER OD6 X ID3.2 X 4.5mm 2
41 25-022-1239-90 L BRACKET R.1 3
42 25-022-1210-90 FAN SCREW BRACKET 4
43 25-022-1233-90 SUBFASCIA T752 R.5 1
44 25-022-1240-90 FAN MOUNTING BRACKET T752 R.2 1
45 25-022-1241-90 SIDE MOUNTING BRACKET T752 2
46 25-022-1231-90 PHONE BRACKET 1
47 25-022-1232-90 DUMMY BRACKET 2
48 25-005-0118-90 HEX SPACER AF5.5 H8+6 10
49 25-022-1242-90 POWER BUTTON BRACKET H=24.8mm 1
50 25-022-1243-90 CLIP THERMAL SWITCH 1
51 23-235-0001-90 BOTTOM CHASSIS T744 R.7 1
52 23-236-0001-90 TOP COVER T744 (GREY) R.4 [FOR GREY VER.] 1
23-236-0002-90 TOP COVER T744 (PAINTED TITANIUM) R.4 [FOR TITANIUM 1
