Board
REGULATOR
U501 01-004-0049-00 IC VOLT REG 12V 1A TO-220 NJM7812 ISOWATT
RESISTORS
R523,R574,R547 02-005-0072-00
RES RN 0.22 OHM 5% 5W SIL STRAIGHT LEADS 3
PIN COMMON PIN2 WW
R571,R545,R522 06-004-0016-90
VR SEMI-FIX RES CF 1K OHM B 30% 6mm VER RM-
063-1K
CAPACITORS
C505,C517,C529 03-002-0014-00 CAP ELEC GR 470uF 16V 20% 85C RAD ST5
C552,C553,C551 03-002-0131-00
CAP ELEC SS 10uF 50V 20% 85C RAD HEIGHT=
7mm MAX
C580,C581,C582 03-002-0133-00
CAP ELEC SS 100uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C522,C535,C534,C521,C511,C510 03-002-0134-00 CAP ELEC GR 100uF 100V 20% RAD
C577,C578,C579 03-002-0137-00
CAP ELEC SS 1uF 50V 20% 85C RAD HEIGHT=
7mm MAX
C565,C566 03-002-0143-00
CAP ELEC SS 47uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C501,C513,C525 03-002-0148-00
CAP ELEC SS 4.7uF 50V 20% 85C RAD
HEIGHT=7mm MAX
C537-C539 03-004-0031-00 CAP MPF 0.1uF 63V +/-5% MEM
C503,C527,C515 03-006-0046-00 CAP MYLAR 1000P 100V 10% ST4.0
C508,C519,C531 03-006-0047-00 CAP MYLAR 150nF 100V 10% ST7.5
TRANSISTORS
Q516,Q518,Q529,Q530,Q504,Q506 05-001-0065-00 XTR PW NPN 1A/100V TO-126 2SD600KE
Q505,Q508,Q517 05-001-0068-00 XTR PW PNP 1.5A/160V TO-220ML 2SA1606E
Q541 05-001-0069-00 XTR PW 3A/60V TO-126 2SB772Q
Q547 05-001-0076-00 XTR SS NPN HFE20 250MHz DTC123ESATP
Q542 05-001-0077-00 XTR SS NPN HFE270-560 180MHz 2SC1740STPS
Q527,Q501,Q502,Q503,Q511,Q513,Q5
14,Q515,Q523,Q526,Q535,Q525
05-001-0079-00 XTR SS NPN HFE160-320 130MHz 2SC2362KF
Q567,Q561,Q564 05-001-0083-00 XTR SS PNP HFE 280-560 110MHz 2SA1016KG-AA
Q509,Q521,Q534 05-001-0100-90
TRANSISTOR PW DARLINGTON PNP 10A/150V TO-
3PB 2SB1560
Q533,Q522,Q510 05-001-0101-90
TRANSISTOR PW DARLINGTON NPN 10A/150V TO-
3PB 2SD2390
COILS
L502,L503,L501 07-002-0136-90 AIR COIL 0.2uH +/-10% 1 X 9 X 13.5 TURNS
RELAY
M506 07-005-0039-90
RELAY POWER DC24V 5A/250V 2P1T PCB ME-
7C024-2HS
JUMPER BARS
J1-J18 17-016-0043-90 JUMPER BAR DIA1.5 X 25 R.1
Q507B/E, Q508B/E, Q519B/E,Q520B/E,
Q531B/E, Q532B/E
17-016-0080-90
Jumper Wire Dia. 0.5mm For L Smaller than 14mm
Roll
