NAD T744 - Page 55

55
Reference No. Database Part No. Descri
p
tion
THERMISTOR
M504 20-004-0039-00
THERMISTOR PTC 100 OHM
PTH9MO4BH471TS2F333
THERMAL PROTECTOR
M505 20-004-0043-90 THERMAL CUT OFF SWITCH 90C ST-22
DIODES
D501-D503,D505-D507,D509-D511,
D521,D524-D528, D531-D536
04-001-0001-00 DIODE SW 4NS DO35 1N4148
D529,D530 04-002-0046-90 DIODE ZENER BZX55 22V 1/2W 5% DO-35 BZX-C22
SURROUND AMP BOARD
PCB ASSEMBLY 27-910-0744-90 T744AH
(
US
)
Surround Am
p
Board Assembl
y
RESISTORS
R843,R844 02-005-0072-00
RES RN 0.22 OHM 5% 5W SIL STRAIGHT LEADS 3
PIN COMMON PIN2 WW
R836,R835 06-004-0016-90
VR SEMI-FIX RES CF 1K OHM B 30% 6mm VER RM-
063-1K
CAPACITORS
C809,C810 03-002-0014-00 CAP ELEC GR 470uF 16V 20% 85C RAD ST5
C554 03-002-0073-00
CAP ELEC GS 22uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C847,C848 03-002-0133-00
CAP ELEC SS 100uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C820,C819,C821,C822 03-002-0134-00 CAP ELEC GR 100uF 100V 20% RAD
C845,C846 03-002-0137-00
CAP ELEC SS 1uF 50V 20% 85C RAD HEIGHT=
7mm MAX
C801,C802 03-002-0148-00
CAP ELEC SS 4.7uF 50V 20% 85C RAD HEIGHT =
7mm MAX
C823-C824 03-004-0031-00 CAP MPF 0.1uF 63V +/-5% MEM
C806,C805 03-006-0046-00 CAP MYLAR 1000P 100V 10% ST4.0
C815,C816 03-006-0047-00 CAP MYLAR 150nF 100V 10% ST7.5
TRANSISTORS
Q809,Q811,Q810,Q812 05-001-0065-00 XTR PW NPN 1A/100V TO-126 2SD600KE
Q807,Q808 05-001-0068-00 XTR PW PNP 1.5A/160V TO-220ML 2SA1606E
Q543,Q544,Q829 05-001-0076-00 XTR SS NPN HFE20 250MHz DTC123ESATP
Q805,Q545,Q546,Q801,Q802,Q804,Q8
06,Q821,Q822,Q803
05-001-0079-00 XTR SS NPN HFE160-320 130MHz 2SC2362KF
Q844,Q512,Q841 05-001-0083-00 XTR SS PNP HFE 280-560 110MHz 2SA1016KG-AA
Q820,Q819 05-001-0100-00
TRANSISTOR PW DARLINGTON PNP 10A/150V TO-
3PB 2SB1560
Q818,Q817 05-001-0101-00
TRANSISTOR PW DARLINGTON NPN 10A/150V TO-
3PB 2SD2390
COILS
L801,L802 07-002-0136-90 AIR COIL 0.2uH +/-10% 1 X 9 X 13.5 TURNS
RELAYS
M501,M502,M801 07-005-0039-90
RELAY POWER DC24V 5A/250V 2P1T PCB ME-
7C024-2HS
JUMPER BARS
J21-J35 17-016-0043-90 JUMPER BAR DIA1.5 X 25 R.1
Q813B/E, Q814B/E, Q815B/E,Q816B/E 17-016-0080-90 Jum
p
er Wire Dia. 0.5mm For L Smaller than 14mm
