NAD T744 - Page 56

56
Reference No. Database Part No. Descri
p
tion
DIODES
D522,D523,D801-D806,D809,D821-
D824
04-001-0001-00 DIODE SW 4NS DO35 1N4148
AUDIO BOARD
PCB ASSEMBLY 27-919-0744-90 T744AH
(
US
)
Audio Board Assembl
y
CAPACITORS
C317-C319,C320-C329,C331 03-002-0129-00
CAP ELEC SS 10uF 16V 20% 85C RAD HEIGHT
=7mm MAX
JACKS
M303 15-003-0027-90 RCA JACK 4 R-R/W-W PCB MOUNT GOLD
M302,M301 15-003-0029-90
RCA JACK 6 R-R-R/W-W-W PCB MOUNT GOLD
RCA-653D-04
(
W/COVER
)
SMD RESISTORS
J3101-J3104 02-007-0089-00 RES SMD 0 OHM +/-5% 1/10W 0805
COMPONENT VIDEO BOARD
PCB ASSEMBLY 27-932-0744-90 T744AH
(
US
)
Com
p
onent Video Board Assembl
y
CAPACITORS
C4310-C4312,C4325,C4327-C4328 03-002-0129-00
CAP ELEC SS 10uF 16V 20% 85C RAD HEIGHT
=7mm MAX P =1.5
C4316,C4318,C4320 03-002-0135-00 CAP ELEC GS 1000uF 10V 20% 85C RAD ST5
C4313,C4314,C4315 03-002-0137-00
CAP ELEC SS 1uF 50V 20% 85C RAD HEIGHT=
7mm MAX P =1.5
C4304,C4305,C4303,C4302,C4301,C4
306
03-002-0157-00
CAP ELEC SS 2.2uF 50V 20% 85C RAD
HEIGHT=7mm MAX
JACKS
M431,M432,M434 15-003-0025-90 RCA 3 G-BL-R PCB MOUNT GOLD
(
W/COVER
)
ICS
U4305 01-012-0059-00 IC LOGIC QUAD 2-INPUT NAND GATE SOP
U4304 01-012-0066-00 IC LOGIC HEX INVERTER SMD SOP 74HCU04DT
U4302,U4303 01-012-0067-00
IC LOGIC ANALOG
MULTIPLEXER/DEMULTIPLEXER SMD SOIC-16
U4301 01-026-0001-90
IC VIDEO 3-CHANNEL 75 OHM DRIVER SSOP
BA7660FS
SMD CAPACITORS
C4329,C4330,C4332,C4333 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603 TAPE
DIGITAL INPUT BOARD
PCB ASSEMBLY 27-921-0744-90 T744AH
(
US
)
Di
g
ital In
p
ut Board Assembl
y
CAPACITORS
C1222,C1223 03-002-0133-00
CAP ELEC SS 100uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C1213,C1214 03-002-0157-00
CAP ELEC SS 2.2uF 50V 20% 85C RAD
HEIGHT=7mm MAX
OPTICAL FIBRE
J1005,J1006 04-009-0001-90
FIBER OPTIC RECEIVING MODULE 650nm 180ns 5V
MOF-R3C2
