NADEX MDM22-M01A - User Manual

Questions and Answers

K
kendra68Aug 8, 2025
What to do if the tip voltage measurement cannot be performed on NADEX Voice Recorder?
- R
  Richard WardAug 9, 2025
  If you can't measure the tip voltage on your NADEX Voice Recorder, first ensure the voltage detection cable is securely connected between the tips. If the display shows " ?.?? V .", it means there's a tip voltage overflow error, and the voltage is outside the specification range (more than 5.00V). Use it within specified limits. If the display shows " - .- - V .", it indicates a measurement impossible error, possibly due to cycle overflow, current value overflow/under flow, or cycle/impulse setting errors. An error should not occur.
C
Cathy WagnerAug 15, 2025
How to fix a NADEX Voice Recorder when the power supply is not turned on?
- A
  Amy BakerAug 15, 2025
  If the power supply of your NADEX Voice Recorder isn't turning on, it's likely that the battery voltage is low. Charge the device, referring to the charging method described in the manual.
L
Lisa BruceAug 20, 2025
What to do if NADEX MDM22-M01A Voice Recorder cannot measure, even if it welding?
- M
  Maurice RodriguezAug 20, 2025
  If your NADEX Voice Recorder can't measure even during welding, check if it's in menu mode. If so, hit the "DISP" key to change to measurement mode.
J
Jessica JohnsonAug 27, 2025
How to fix 'Memory Error' on NADEX MDM22-M01A?
- D
  Daisy SandersAug 27, 2025
  If your NADEX Voice Recorder displays "Memory Error", it means the setting and measurement data have been corrupted. To resolve this, push any key. The LCD will display the initial screen "Data Initialize" -> "0.0CY 0.00kA", which compulsorily resets the memory. Note that memory recovery isn't possible.
M
Monica SimmonsNov 2, 2025
Why can't I measure the current value with my NADEX MDM22-M01A Voice Recorder?
- M
  maryrhodesNov 2, 2025
  If the NADEX Voice Recorder displays ".??kA.", it indicates a current under flow error. Check the measurement range; if it's on Hi range, switch to Lo range. Note that if it’s already on Lo range, the current is outside the specification range. If the display shows "??.???A.", it's a current overflow error. Check the measurement range; if it's on Lo range, switch to Hi range. If it is already on Hi range, the current is outside the specification range. If the display shows "##?#CY" or "#####ms.", there's an impulse setting error. Input a suitable value for the number of setting impulses. If the display shows " !!.!CY " or " !!!!ms . ", it's a cycle setting error. Ensure the measurement start time isn't longer than the weld time and that the measurement end time isn't longer than the measur...

Summary

Important Safety Precautions

Understanding Safety Symbols

Explains hazard symbols like Danger, Warning, Caution, and specific electrical, fire, temperature warnings.

General Danger Precautions

Details precautions regarding cables, AC adapters, and charging to prevent electric shock, fire, or explosion.

General Warning Precautions

Component Identification and Functions

Device Controls and Interfaces

Details the function of each component, including POWER, DISP, MENU, SEL keys, connectors, display, and lamps.

Measurement Procedures and Notes

Measurement Operation Procedure

Step-by-step guide on attaching CT coil, powering on, setting conditions, and connecting voltage cable.

CT Coil Usage (Page 14)

CT Coil Usage Safety Warning (Page 15)

Warns to use caution when hooking up the CT coil to the welding machine to avoid injury.

Tip Voltage Detection Cable Usage

Menu and Setting Functions

Navigating Menu Options

Data Communication and Connectivity

USB Communication Setup

Bluetooth Wireless Communication Setup

Charging the Device

AC Adapter Charging Procedure

Steps for charging using the attached AC adapter, including charge lamp indicators.

Charging Safety and Battery Warnings

Warns against using unauthorized adapters, heat generation during charging, and low battery indication.

Error Handling and Troubleshooting

Error Display Codes and Meanings

Lists error codes displayed on the LCD for measurement, setup, and system faults.

Troubleshooting Common Issues

Provides solutions for common problems like no power, measurement failures, and display errors.

Troubleshooting Specific Errors

Addresses specific issues like tip voltage errors, memory errors, and system faults with resolution steps.

Technical Specifications

Measurement Specifications

NADEX MDM22-M01A Specifications

General

Recording Format	WAV
Memory	8GB
USB	USB 2.0
Battery	Rechargeable Lithium Battery
Playback	Yes, via built-in speaker or headphones
Microphone	Built-in high sensitivity microphone
