Mesurement Method
4-2. The display of a liquid crystal display
If welding is performed, measured value will be displayed as follows. Moreover, the switch of a
display can be performed by the [DISP] key.
Whenever it presses the [DISP] key, switching display of weld time , weld current , tip voltage , weld
counter , and remain of memory.
(Example of a display)
The following is displayed when ms is chosen.
weld current
weld time(cyc)
voltage between tips
weld counter
remainder of memory
R E M A I N M . 1 0 0 0 0
1 5 . 0 C Y 1 1 . 5 0 k A
V21.0
W . C O U N T 3
weld currentweld time(ms)
0 m s52 1 1 . 5 0 k A
