TY-GC31-004A 3/24
Rev.B
1. Specifications
Pressure range -100 ～ 100 kPa (100)
(Max. pressure -100 ～ 500 kPa (500)
display digit) 0 ～ 1.0 MPa -0.1 ～ 1.0 MPa (1.000)
0 ～ 2.0 MPa -0.1 ～ 2.0 MPa (2.00)
0 ～ 3.5 MPa (3.50)
0 ～ 5 MPa (5.00)
0 ～ 10 MPa (10.00)
0 ～ 20 MPa (20.0)
0 ～ 35 MPa (35.0)
0 ～ 50 MPa (50.0)
Display range From -10 to 110 %F.S. of the pressure range or from -1999 to 1999
(display value)
Max allowable Two times of pressure range (less than 35 MPa)
environment 1.5 times of pressure range (35 MPa or higher)
Applicable liquid Air, water, and oil, etc.. (Non-corrosive gas/liquid)
Environment used Under normal conditions, do not use a location where flammable or
Explosive gasses or liquids are present.
Connecting screw *1 R1/8 (with M5 female screw) Range: less than 1MPa
R1/4, G1/4B
Accuracy Display accuracy ±(1.0 %F.S. + 1 digit) at 23 ℃
Temperature characteristic ±0.1 %F.S./ ℃ (Both zero and span)
Power source 12 - 24 VDC ±10% Ripple voltage : 10%(P-P) or lower
Current consumption Less than 30m ADC (Not including current of comparator output)
Display Pressure display 3 1/2 digit LED (Height of characters : 10 mm)
Operation display Red LED X 2 (Lit when turned ON)
Display cycle 0.2 s
Output Comparator output *1
NPN open collector × 2 outputs
PNP open collector × 2 outputs
Response Less than 5 ms
Output NPN 30 VDC, 80 mA max.
capacity PNP 24 VDC (Range of supply voltage),
80 mA max.
Dead band.
Hysteresis :variable
Window comparator :1%F.S. Fixed
Delay 0.00～2.00 s (Both ON /OFF)
To Next Page
