NAC 152 XS Preamplifier
17.3 NAC 152 XS Connected to FlatCap XS Power Supply (stage 1 upgrade)
mains input
and fuse
power
switch
for preamplier stage 2
upgrade, CD5 XS, Headline
or phono stage. Additional
interconnects required.
to power amplier with
internal power supply
cable
direction
marker
4 to 4 pin DIN
Interconnect Cables
240° 5 to 5 pin DIN
