NAIM NAIT 50 - Specifications

10
10. Specications
Audio Specications
Power Output (Speakers) 25 Watts into 8 @0.1% THD+N @ 230VAC
Power Output (Headphones) 1.5W into 16
1/4" (6.35mm) Jack
Gain Phono stage: 40dB (@1kHz RIAA)
Pre-amp stage (and headphones): 16dB
Power amp stage: 29dB
Inputs 2x Stereo 5 pin DIN, 47k line level
1x Stereo RCA 47k, 5mV MM level
Frequency Response Via line: -3dB @ 4Hz to 45kHz
Via phono: -3dB @ 6Hz to 30kHz
Hardware Specications
Dimensions (H x W x D) 87 × 207 × 321mm (including feet)
Weight 4.5kg (amplier only)
Passive Consumption 20W (idle)
Standby Consumption <0.5W (auto standby with music sensing)
Mains Supply 110V - 120V, 220V - 240V 50/60Hz
Fuse 230V = T1AL (anti-surge) ; 115V = T2AL (anti-surge)
Finish ‘Chrome bumper’
Front and rear - black aluminium anodised
Cover - black powder coat
Operating Temperature 5-35°C
Storage Operating Temperature 0-50°C
