Page 50
6-2-3-2 Switch Test
1. Select SWITCH TEST on the I/O Test screen to test the switches and
sensor. The following screen is displayed.
UP SELECT SW+ENTER SW:EXIT
SWITCH TEST
COIN 000
SERVICE OFF
TEST ON
UP SELECT OFF
DOWN SELECT OFF
ENTER OFF
START 1P BUTTON OFF
START 2P BUTTON OFF
GUN 1P TRIGGER OFF
GUN 2P TRIGGER OFF
SENSOR OFF
I/O TEST
Each time a coin is entered the COIN numbers will increase by one.
While a switch is pressed or the sensor is activated the corresponding display will
change from OFF to ON.
Press the UP Select switch and the Enter Switch together to return to the Main Menu
Screen.
