59
AIR INTAKE
WARNING !
Carry out these operations when the engine is stopped
and cold. Make sure that no dust or dirt enter the intake
manifold.
The reliability and the performances of the engine
depend among other things on the quantity and the
temperature of the global air intake design.
CHECK THE AIR FILTER
1. Remove the holding clamps and remove the lter (in
blue on the picture).
2. Replace or clean the element.
3. If the air lter is crushed, flattened or punched,
replace it.
4. Install the new lter with new clamps. Do not
overtight, and not damage the inlet mouth.
Typical long life NANNI air lter
S08 MAINTENANCE
CLEANING THE AIR FILTER
Special tool
For best results, order the NANNI lter cleaning kit :
Number Description Illustration
970317077 Kit air lter cleaner
EN, ESP, SUOMI
OIL
SPRAY
CLEANER
SPRAY
970317078 Kit Air lter cleaner
FR, IT, DEU
Long life NANNI air lters require periodic cleaning.
Maintenance of these air lters is very simple. Please
follow the 4 steps below.
Cleaning: Spray liberally the
NANNI cleaner onto both sides
of the lter and let it soak for 10
minutes to loosen dirt. Do not
allow cleaner to dry up on the air
lter.
Rinsing: Wash the lter with
cold water at low pressure on
the outside to flush dirt out of
the lter. Continue rinsing until
removing all traces of cleaner.
You may need to repeat steps 1
and 2 several times.
Drying: After rinsing, shake off
any excess of water and let it
dry naturally. Do not oil the lter
before it is completely dry.
Oiling: Spray oil (Aerosol) evenly
on the crown of each pleat while
maintaining the nozzle at
approximately 8 cm from the
lter. Allow oil to penetrate into
fabric for around 20 minutes.
Respray oil wherever some
white spots are still visible on
sides of the lter until there is a uniform blue color
throughout.
