45
On Eco 4, only the oil pressure and battery charge lamp
light on.
3. Press the Start button halfway (position 1/2) to start
preheating. Hold the button for 10 to 20 seconds,
depending on ambient temperature to preheat the
engine.
POSITION 1
POSITION 1/2 : preheating
POSITION 2
4. Press fully (position 2) to start the engine. Once the
engine has started, release the button, all lamps go
out.
POSITION 1
POSITION 1/2
POSITION 2 : start
5. If the engine is t with water cooled exhaust elbow,
check that raw water flows from the exhaust outlet
at the hull. If the water does not flow, stop the engine
and check the raw water system.
Electronic type 5:
Turn the ignition key to the ON position.
It is not required to start the engine for system initializa-
tion. The tachometer will start an autimatic self-test at
every powering up. This self test is as follows :
1. The L.C.D screen displays the current inbed software.
2. All dial indicators will be checked : pointers will sweep
up to full scale, then will return to the current value;
3. when self-test is completed, the LCD screen will dis-
play data.
4. If the C5 is powered for the rst time, the user will be
prompted to the system set-up.
ENGINE STARTED
To insure adequate lubrication, operate engine at or
below 1200 rpm with no load for 1-2 minutes. Extend
this period to 2–4 minutes at freezing or sub-zero
temperatures.
1. Check oil pressure gauge as soon as engine starts.
If gauge needle does not level up to minimum oil
pressure specication within 5 seconds, stop the
engine and determine the cause.
2. Watch coolant temperature gauge. Do not place
engine under full load until properly warmed up.
It is a good practice to operate the engine under a lighter
load and at lower speeds than normal for the rst few
minutes after start-up.
S07 STARTING & RUNNING
