Nanni V6.270 - Principal Parts of the Engine

1. Engine alternator
2. Engine alternator belt
3. Starter
4. Air filter
5. High pressure injection fuel pump
6. Throttle lever
7. Fuel filter
8. Exhust elbow
9. Fuel fill orifice
10. Oil drain orifice
11. Oil gauge
12. Oil filter
13. Heat exchanger
14. Coolant fill orifice
15. Seawater pump
16. Heat exchanger drain plug
17. Electronic control unit
18. Supports
19. Turbocompressor
20. Hoisting eyes
21. Fuses
