NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Installation Instructions, Volume 2 Page 41
remain on the premises) without causing an alarm. This feature is enabled in the factory program.
Auto-Reset
Auto-Reset after Burg Bell Timeout
If a zone detects an alarm condition and is selected for Auto-Reset, it will automatically rearm itself as soon as the alarm con-
dition is cleared. Auto-Reset may be delayed to occur after the Burglary Bell timeout period by selecting Auto-Reset After
Burglary Bell Timeout and Auto-Reset. Zones that are not programmed for Auto-Reset will not be capable of signaling
another alarm until (a) the cause of the alarm has been corrected and (b) the control panel is disarmed. Also see Swinger
Shutdown.
Auxiliary Relay (Called "Burg PGM1 Relay"; see section "Control Panel Outputs" earlier in this manual).
Backup Reporting Telco #1 / Telco #2
Normally, ten attempts to communicate will fail before Fail to Communicate trouble is triggered. If Backup Reporting is se-
lected and the communicator does not reach the first telephone number after five attempts, five attempts will be made to
reach the second telephone number before a Fail to Communicate trouble is triggered. Enter Subscriber Identification
Numbers for Telephone 2 and other information required for Telephone 2. Also program Backup Report on Telco 2. Any
zone programmed to report to Telco 1 will backup report to Telco 2. Note: Subscriber Identification Numbers for both Tele-
phones 1 and 2 must be entered, even if they are the same.
Battery
The control panel motherboard has 24V battery backup used to provide backup protection in the event of a power loss.
These batteries are an integral part of the system and must be installed, even if AC power is present. Change the batteries
every 4 years or as required.
If the GEMC-BM/PS is used, it requires 12V battery backup.
BE
Bypass Enable (Alarm Code feature)
Allows alarm code user to bypass zones if security bypass is enabled.
Bell Control
In any system, the ability to silence any combination of alarm devices (outputs) initiated from any area. Bell Control must be
programmed for all systems to be able to silence an alarm. For example, in an 8-area system, each area could be pro-
grammed to silence only those alarms initiated within its own area; or any area could be programmed to silence an alarm initi-
ated from another area.
Blocked View Option for User Codes see BV
Burg Alarm with RF/SLC Tampers on Armed Area
Enable this feature to allow Burg Bell activation upon any Burg RF/SLC tamper violation within an armed area. To report to
the central station, program this feature in the Quickloader System Assignment screen, System Reporting and Outputs
tab.
(Burg) Alarm Supervision
(Burg) Bell Supervision
The Burg Bell output, supervised with a 2.2K EOLR, if shorted or opened, the keypad will display an E51 trouble. Note: E51
trouble may also be generated with a GEMC-BM or GEMC-BM/PS trouble. To report to the central station, program this fea-
ture in the Quickloader System Assignment screen, System Reporting and Outputs tab.
Burg AUX Relay
GEMC-BM and GEMC-BM/PS Form-C relay outputs, programmable by zone. Remove shunt "R" to change from wet to dry
contacts.
Burg Low Battery
The GEMC-BM/PS charges and monitors its separate 12V battery; when this battery is detected as having low voltage, the
GEMC-BM/PS generates a "BURG MOD LOBATT, E63-00 SERVICE" system trouble. The GEMC-BM/PS performs an active
battery test every 4 hours.
Burg PGM1
Burg PGM2
GEMC-BM and GEMC-BM/PS outputs that go active low. Enabled by zone and programmable timeout for each.
BURGLARY GLOSSARY
