NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Installation Instructions, Volume 2 Page 43
quently be established. Note: For Fire systems, the GEMC-FK1 keypad must be unlocked before downloading.
Program Disable Callback Download to prevent unauthorized downloading to an unattended panel. Program Disable Key-
pad Function-Mode Download to prevent downloading at the keypad. Note: For Fire systems, the keypad must be
unlocked and Enable Programming must be selected in the Function Menu.
Callback-Method Download: If Callback #1 or Callback #2 are selected, after establishing a connection, the panel will im-
mediately disconnect and call back on the associated Callback number (program in the Dealer Program Area screen, Site
Number field in Quickloader).
Cancel
Cancel Code
Cancel Window Duration (Report Cancel Window)
Enable Cancel Report to Telco 1 / Telco 3
CANCEL is the preventing of a report from being sent by entering a user disarm code. If the area is disarmed during Entry
Delay or the "Pre-Alarm Warning", then no report will be sent and no messages will be displayed at the keypad. If the area is
disarmed during the Abort-Delay, then an "Alarm Canceled' will be displayed at the keypad and no report will be sent. If the
area is disarmed during or within the Cancel Window Duration, then an "Attempting to Cancel" will be followed by an "Alarm
Canceled" for a successful cancellation. Otherwise, the report had been sent and will be responded appropriately to by the
Central Station. Cancel must be provided with a Central Station Telephone Number, proper Subscriber O/C Report ID Num-
bers and a valid Cancel Code to Telco 1/3. A Cancel Window ("Report Cancel Window") is the duration that the system will
attempt to cancel a report, after the report is sent.
Central Station: Report Zone Wireless Trouble/ Restore to Telco 1 / Telco 3
Send Zone Wireless Trouble/ Restore report(s) to Telco 1/3. See the Keypad Trouble Messages table at the beginning of
this volume.
Chime
This annunciator feature may be used on any zone to sound a tone at the keypad while disarmed when the zone is faulted.
Access the ACTIVATE CHIME function to enable or disable the Chime Mode from the keypad. This feature is programmable
by zone and for duration of tone (see Time Selection). A time (in ¼ seconds) must be programmed for the chime to function.
Chime 2
For a distinct pulsating "Chime Zone" tone, program the zone for Chime 2. This feature allows zones to have distinctive an-
nunciator chime to identify the door(s) or zone(s). "Chime" must be enabled on any keypad for all area keypads to chime.
Clear Program
Caution: Erases the dealer program. Use this feature to start a new customized default program. Access address in the
Programming Instructions (WI1673), then press ENTER.
Closing Report
Closing Report Only on Conditional Close
Conditional Closing
Include Selective/Group Bypass In Conditional Close/Status
Status Report
On arming, the communicator can transmit a unique Closing Code for each user and a status report that identifies the prob-
lem zone to the central station. Note that Subscriber Identification Numbers and a Closing Code must be entered for any
closing report.
Select which users will report closings for each telephone number, even if Closing Report Only on Conditional Closing is se-
lected. Normally, a closing report will consist of the Closing Code and the number of the user that armed. If the user armed
with an auto-bypassed zone (or selective/group bypassed zone if Include Selective/Group Bypass In Conditional Closing/
Status was programmed), the Conditional Closing Code will also be sent.
Select Closing Report Only on Conditional Closing to report only when arming with an auto-bypassed zone (and selective- /
group-bypassed zone if Include Selective/Group Bypass in Conditional Closing/Status is programmed).
Select Status Report to send a closing followed by a status report that identifies the problem zone(s).
Cold Start
Caution: Erases the entire program (codes, schedules, etc.), leaving the panel as it came right out of the box. Access ad-
dress in the Programming Instructions (WI1673), then press ENTER.
Data Format
Ask the central station which of these formats to use.
1400Hz Handshake/Kissoff. 1400Hz Handshake overrides 2300Hz Handshake if both are selected.
2300Hz Handshake/Kissoff. Used with the following receiver formats: Radionics, DCI & Franklin Slow; Radionics Fast;
BURGLARY GLOSSARY
