Sescoa, Vertex, DCI & Franklin Fast; Radionics BFSK. 1400Hz Handshake overrides 2300Hz Handshake if both are se-
lected.
Modem Formats. Modem formats (SIA and Point ID) are preset and automatic but require a Type for each zone. Program
Zone Type as follows: Fire* = "1" (Note: Not for Modem 2 Receivers); Panic = "2"; Burglary = "3"; Holdup = "4"; Gas Alarm =
"7"; Heat Alarm = "8"; Auxiliary Alarm = "A" (Keypad displays "0"); 24-Hour Aux. Alarm = "B".
Compatible Receivers. The following receivers are compatible with the GEMINI C-Series control panels.
• Ademco MX-8000
• Surgard MLR-2
• Osbourne Hoffman 2000e
• NAPCO Net.Link™ NL-RCV-RMPCUL
• Ademco 685
Day Zone/Trouble (Open; Short)
Alarm on Day Zone/Trouble
Disable Auto-Reset in Day Zone/Trouble
Reset Day Zone/Trouble with Arm/Disarm Only
Enable Day Zone/Trouble Watch, Areas 2-8 (By Area)
A Day Zone/Trouble will give an audible and visual indication at the keypad if there is a problem on the loop while disarmed.
Open- and short-circuit conditions are programmed separately, by zone. This feature may be used to warn of a problem (a
break in a window foil, for example) during the day, when the panel is not normally armed. When the Day Zone/Trouble is
tripped, "DAY ZONE TRBL" and the zone number(s) will alternately display at the keypad and the sounder will pulse. Press
RESET to silence the sounder and reset the keypad. "ZONE FAULT" will be displayed until the condition is corrected. If Reset
Day Zone/Trouble With Arm/Disarm Only is programmed, arm and disarm the panel to reset the Day Zone/Trouble indica-
tion at the keypad.
If Alarm on Day Zone/Trouble is programmed for a zone, a Day Zone/Trouble condition will cause the alarm outputs pro-
grammed for that zone (sirens, relays) to activate.
Note: (1) If a zone is programmed for both Day Zone/Trouble Open and Day Zone/Trouble Short, either condition must be
reset before the other can activate. (2) Day Zone/Trouble Short will not function if No EOL Resistor is also programmed.
Report Trouble or Trouble Restore is programmed in conjunction with Day Zone/Trouble Open/Day Zone/Trouble Short and
Trouble on Open/Trouble on Short (the trouble reported will be that programmed under Day Zone/Trouble Open and/or Day
Zone/Trouble Short).
Note: Do not program a Day Zone/Trouble for 24-hour protection. The keypad will annunciate as a Day Zone/Trouble but
the panel will transmit an Alarm Code and a Trouble Code when tripped.
Program Disable Auto-Reset on Day Zone/Trouble to prevent repeated Day-Zone/Trouble trips. This will cause the keypad
display and sounder to activate only once in any arm/disarm period.
If Enable Watch is selected (by area), zones programmed for Day Zone/Trouble can only be activated when ACTIVATE
WATCH is accessed. Arming and disarming will turn off the Watch Mode. If Report Trouble is selected, a trouble on a Day
Zone/Trouble will be reported only when the Watch Mode is on.
Dealer Keypad Program Code
This code is left blank in the control panel memory at the factory and may be added by the dealer (in possession of the Master
Security Code which is the unchangeable code printed on a motherboard label). The Dealer Keypad Program Code allows
the same access to programming functions as the Master Security Code. Note: To comply with SIA CP-01, the number of
digits in the Dealer Keypad Program Code determines the number of digits (no more or less) that MUST be used for all Burg
User Codes.
Dealer Security Code See Master Security Code
Delayed Trip 1 and Delayed Trip 2. (Refer to NAPCO manual WI1047).
2 programmable Trip Delays that provide a "hold-off" of an alarm indication and central station report until the selected zone
(s) have been violated for the programmed Trip Delay duration. The 2 Trip Delays are programmable in minutes from 2 to
255 (4 hours 15 minutes). Typically used for non-Burglary applications, such as refrigeration temperature control.
Digital Dialer Test
Activating the digital dialer test from the Function Menu (ACTIVATE DIALER TEST) will send the programmed report code to
the central station. Program DD TEST for SYSTEM-TROUBLE REPORTS and enter a DD TEST Report Code. Note that in
this case the report code received is not indicative of a system trouble, but is an indication of a successful transmission.
Should the transmission fail, the keypad will display "E03-00 COMM FAIL". This system trouble may be reset by pressing the
RESET button. Any successful subsequent report will also clear the system trouble.
