NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Page 60 Installation Instructions, Volume 2
Trouble on Open
Trouble on Short
Trouble on Night Open (Not for UL installations)
Trouble on Open will identify an open circuit on a loop as a trouble. Trouble on Short will identify a short circuit as a trouble.
Trouble on Night Open, which will identify an open circuit on a normally-closed zone while armed as a trouble condition (not
an alarm), is intended for use with a Napco Monitor-Series dual-technology sensor. While there will be no indication at the
keypad, any of these trouble conditions can be reported if Report Trouble is programmed as well. See Sensor Watch.
Trouble/Trouble Restore Telco 1/Telco 3 See Report Telco 1/Telco 3
BURGLARY GLOSSARY
1st BOX
2nd BOX
tx16 tx1
Time t:
Entry:
0
*
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 0
11 B
12 C
13 D
14 E
15 F
* = blank
TIME SELECTION
TIME UNITS MAX. PROG. TIME
UL864 Required
settings
EXIT DELAY SECONDS 4 MIN., 15 SEC. (255 SEC.)
(4)
N/A
ENTRY DELAY 1 SECONDS 4 MIN., 15 SEC. (255 SEC.)
(4)
N/A
ENTRY DELAY 2 SECONDS 4 MIN., 15 SEC. (255 SEC.)
(4)
N/A
AC-FAIL x10 MINUTES 42 HR, 30 MIN. (2550 MIN.) 60-180 minutes
ABORT DELAY SECONDS 4 MIN., 15 SEC. (255 SEC.)
(3)
000 for Fire Zones
SENSOR-WATCH
(DISARMED)
HOURS
255 HOURS
(6)
This feature only affects zones programmed for
"Sensor Watch"; Fire Zones may not be programmed
for Sensor Watch
BURG BELL MINUTES 4 HR, 15 MIN. (255 MIN.)
(1)(2)
DISABLED
PULSE-BURG BELL MINUTES 4 HR, 15 MIN. (255 MIN.)
(1)(2)
N/A
BURG PGM2 MINUTES 4 HR, 15 MIN. (255 MIN.)
(2)
N/A
CHIME ¼ SECONDS 63.25 SEC. (255 QTR-SEC.)
(3)
N/A
BURG AUX RELAY MINUTES 4 HR, 15 MIN. (255 MIN.) N/A
BURG PGM1 MINUTES 4 HR, 15 MIN. (255 MIN.)
(2)
N/A
BURG PGM1
ACCESS CONTROL
SECONDS 4 MIN., 15 SEC. (255 SEC.) N/A
AUTO DISARM/REARM DELAY MINUTES 4 HR, 15 MIN. (255 MIN.) N/A
REPORT CANCEL WINDOW MINUTES 4 HR, 15 MIN. (255 MIN.)
N/A
WATER FLOW RETARD TIME SECONDS 4 MIN., 15 SEC. (255 SEC.)
Max 90 seconds less inherent delay of the waterflow
sensor.
SHED BURG ON AC FAIL x10 MINUTES 42 HR, 30 MIN. (2550 MIN.)
Determined through battery standby calculations.
Refer to Fire Glossary entry.
GEM-TRANS2 / GEMC-WL-WD2 x10 MINUTES 42 HR, 30 MIN. (2550 MIN.) 4 hours (24 x 10 minutes)
GEM-PIR / GEMC-WL-PIR x10 MINUTES 42 HR, 30 MIN. (2550 MIN.) N/A
GEM-SMK / GEM-HEAT / GEMC-WL-
SMK / GEMC-WL-HEAT
x10 MINUTES 42 HR, 30 MIN. (2550 MIN.) 4 hours (24 x 10 minutes)
GEM-DT / GEMC-WL-DT x10 MINUTES 42 HR, 30 MIN. (2550 MIN.) N/A
GEM-GB / GEMC-WL-GB x10 MINUTES 42 HR, 30 MIN. (2550 MIN.) N/A
DELAYED TRIP TIME 1 MINUTES 4 HR, 15 MIN. (255 MIN.) N/A
DELAYED TRIP TIME 2 MINUTES 4 HR, 15 MIN. (255 MIN.) N/A
NOTES:
(1)
The output used for Burglary must be at least 4 minutes in Residential UL installations, 15 minutes in Commercial
UL installations.
(2)
If both locations are left blank, this feature will remain active until the system is disarmed. When both locations are
programmed “F”, maximum time will be 4 hours, 15 minutes (255 minutes).
(3)
If both locations are left blank, this feature will not activate (timeout = 0).
(4)
In UL installations: Maximum Exit Delay = 60 sec; Maximum Entry Delay = 45 sec.
(5)
If programming locations are left blank, delay will default to 10 sec.
(6)
Time in units of disarmed hours (accumulated between armed periods).
