NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Installation Instructions, Volume 2 Page 61
Trouble/Trouble Restore Telco 2 See Backup Report on Telco 2
24-Hour Zone
A zone that provides protection at all times, whether or not the system is armed. If programmed for silent alarm (no Burg Bell,
Burg Module PGM1 Output, Fire Output or Keypad Sounder on Alarm programmed) there will not be any indication on the
keypad. If an Audible output is programmed, the keypad will flash the red Armed LED and display "ALARM" followed by the
zone description.
Note: Do not program a Day Zone/Trouble as a 24-Hour Zone.
Unvacated Premises
Convert from Away to Stay based on no egress through exit door. Default is enabled. (GEMINI C-Series control panels--This
feature is Automatic Interior Bypass/Easy Exit). The panels use the existing programmable feature "Auto Interior Bypass".
This feature is enabled in the factory program. Refer to Programming Manual WI1673 for more information.
User Assignment (see Fire Glossary)
UP
User Program (Alarm Code feature)
Allows alarm code user to enter User Program Mode.
User Closing and Opening Reports by Telephone Numbers
Enable User Code by Area
If reporting to a central station, program User Closing and Opening Reports by Telephone Numbers. In multiple-area sys-
tems, program Enable User Code by Area.
User Code (Burg User Code / Fire User Code)/Authority Levels/Access Bytes
In total, up to 195 Fire User and Burg User Codes may be entered into the system, each with its dedicated Authority Level
and Access Byte. (The Authority Level comprises an Option Code). A short description of each follows:
Burg User Code: For Fire and Burglary combination systems, this code will only allow access to the Burglary functions of the
system. This code is typically used by a person with the responsibility of securing the premises, arming and disarming the
Burglary alarm system, silencing Burglary alarms if they occur, etc. This code is special in that each code can be assigned
four different "Authority Levels" (0. 1, 2 or 3) and five "Attributes" (Initially Off, BV, User Program, BE and Overview) and
can be assigned to Area(s) 2 - 8 (with Area 1 being reserved for Fire only).
The Gemini C-Series control panels are pre-programmed at the factory as follows:
• For Burglary-Only systems: The panel default Burg User Code is programmed as User #1, with digits 123, active in
Area 2 only.
• For Fire and Burglary combination systems: The panel default Fire User Code is programmed as User #1, with digits
"123", active in Area 1 only. The Burg User Code is programmed as User #2, with digits "456", active in Area 2 only.
• For Commercial Fire-Only systems: The panel default Fire User Code is programmed as User #1, with digits 123 active
in Area 1 only.
Unsupervised Transmitters
(Programmable with PCD-Windows Quickloader Download Software Only) Transmitters can now be unsupervised by pro-
gramming a "9" in place of point number "1". NOTE: All points of that transmitter will be unsupervised.
Watch Mode (by Area) See Day Zone/Trouble
Wireless Keyfobs
RF-Receiver/SLC
Wireless Keyfobs are Arm/ Disarm Wireless Remote devices that require the programming of an RF ID number and an area
number; Aux 1 and Aux 2 buttons can be programmed for various options (see the installation instructions included with the key-
fob).
From the "RF-Receiver/SLC" screen in PCD-Windows Quickloader, you can select the RF and SLC Receivers used by the
Gemini C-Series panel. Each address 1-4 can be set for a Receiver. Only addresses 1 and 2 can be used for SLC Receivers
and there cannot be any unused address before the last address used. Each SLC Receiver can also be selected for "Class
A" operation from this screen.
Wireless Trouble Reporting by Zone All reports of Wireless trouble (Transmitter Low Battery, Transmitter Tamper, Transmitter
Supervision Failure) to central station will identify identifying the zone of the transmitter.
Zone ANDing, Groups 1–8 (Not for UL installations); Enable Local Alarm on First Zone AND Trip (Not for UL installations)
Up to 8 groups of at least two zones each can be "AND"ed, wherein the system will go into alarm only if any two zones of the
BURGLARY GLOSSARY
