NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 80 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 9-16 (ADDRESS 2102-2188)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 9 ► 16
Z9 Z10 Z11 Z12 Z13 Z14 Z15 Z16
1 2 3 4 5 6 7 8
Zone Area 1 (Fire) 2144
Zone Area 2 2145
Zone Area 3 2146
Zone Area 4 2147
Zone Area 5 2148
Zone Area 6 2149
Zone Area 7 2150
Zone Area 8 2151
Reserved 2152
Reserved 2153
Zone Anding Group 1 2154
Zone Anding Group 2 2155
Zone Anding Group 3 2156
Zone Anding Group 4 2157
Zone Anding Group 5 2158
Zone Anding Group 6 2159
Zone Anding Group 7 2160
Zone Anding Group 8 2161
Interior 1 Bypass 2162
Interior 2 Bypass 2163
Keypad Sounder on Alarm 2164
Ext Fire Output 1 2165
Ext Fire Output 2 2166
Ext Fire Output 3 2167
Ext Fire Output 4 2168
Ext Fire Output 5 2169
Ext Fire Output 6 2170
Ext Fire Output 7 2171
Ext Fire Output 8 2172
Reserved 2173
Reserved 2174
Carbon Monoxide 2175
Verification (Fire) 2176
Waterflow (Fire) 2177
Supervisory 2178
Monitor Zone 2179
NAC A 2180
NAC B 2181
NAC C 2182
NAC D 2183
Reserved 2184
Reserved 2185
Chime 2 2186
Delayed Trip 1 2187
Delayed Trip 2 2188
ZONE OPTIONS ADDR
ZONES 9 ► 16
Z9 Z10 Z11 Z12 Z13 Z14 Z15 Z16
1 2 3 4 5 6 7 8
Priority Zone 2102
Priority / Bypass 2103
AutoBypass 2104
Selective Bypass 2105
Keyswitch Arming 2106
AutoBypass Re-entry 2107
Pre-Alarm Warning 2108
Never Arm 2109
24-Hour Protection 2110
Burg Bell 2111
Pulse Burg Bell 2112
Burg PGM2 2113
Burg Relay 2114
Burg PGM1 2115
Exit/Entry #1 2116
Exit/Entry #2 2117
Exit/Entry Follower 2118
Auto Reset 2119
Swinger Shutdown 2120
Chime Zone 2121
Abort Delay 2122
Power-Up Delay 2123
Day Zone/Trouble Open 2124
Day Zone/Trouble Short 2125
Alarm on Day Zone/Trouble
2126
Report Alarm Tel1 2127
Rpt Alm Restore Tel1 2128
Report Trouble Tel1 2129
Rpt Tbl Restore Tel1 2130
Reserved 2131
Reserved 2132
Reserved 2133
Reserved 2134
Report Alarm Tel3 2135
Rpt Alm Restore Tel3 2136
Report Trouble Tel3 2137
Rpt Tbl Restore Tel3 2138
No EOL Resistor 2139
Sensor Watch 2140
Trouble on Open 2141
Trouble on Short 2142
Trouble on Night Open 2143
FOOTNOTES AND SYMBOLS FOR TABLES
A
2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
B
If Fire Alarm Verification is selected, then Fire must also be
selected.
C
When the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
D
Disable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.
