NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 97
BURG AREA EVENT REPO RTING OPTIONS (ADDRE SS 8040- 8051)
BURG AREA EVENT REPORTING OPTIONS:
For example, to send (via Telco 1) an Exit Error event report for Area 4, access address 8040, then press 4 to select Area 4.
1. Select the desired event type, either Exit Error, Recent Closing or CP01 Test Signal.
2. Enter the corresponding Area number in each the address location, in Binary (Bit) Format. NOTE: See Direct Address
Programming Example on page 72.
3. Press U to save.
NOTE: Dark shaded data value box shows option not available for that Area. Area 1 is a Fire Area only.
ADDR
AREAS 1 → 8
EXIT ERROR
A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
EVENT REPORT TELCO 1 8040
RESTORE REPORT TELCO 1 8041
EVENT REPORT TELCO 3 8042
RESTORE REPORT TELCO 3 8043
Default = blank (•) from address 8040-8043
ADDR
AREAS 1 → 8
RECENT CLOSE A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
EVENT REPORT TELCO 1 8044
RESTORE REPORT TELCO 1 8045
EVENT REPORT TELCO 3 8046
RESTORE REPORT TELCO 3 8047
Default = blank (•) from address 8044-8047
ADDR
AREAS 1 → 8
CP01 TEST SIGNAL
A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
EVENT REPORT TELCO 1 8048
RESTORE REPORT TELCO 1 8049
EVENT REPORT TELCO 3 8050
RESTORE REPORT TELCO 3 8051
Default = blank (•) from address 8048-8051
To Next Page
