ACM ZONE OPTIONS (ADDRESS 5850 - 5889)
ACM GLOBAL FLAGS (ADDRESS 5890)
ACM TIMEOUTS (ADDRESS 5892-5893)
ACM ZONE OPTIONS:
 Enter the Zone numbers (in decimal 1-255 format) for each option in the table below. Press U to save.
NOTE: Dark shaded data value box shows option not available. Note: The Area # for Door 1 is controlled by the
existing Keypad Programming table (Address 2425 to 2439). The assigned Area for Door #2 for each ACM must be
entered in the table below (addresses 5858, 5868, 5878 and 5888) and must not be left blank if Door 2 is to be used.
Area 1 must never be assigned to an ACM door in any C-Series system.
ACM1 Zone Options
Door 1
ADDR
Door 2
ADDR
Door Contact 5850 5855
Forced Entry Zone 5851 5856
Door Ajar Zone
5852
5857
Area # for Door 2 5858
Reserved
5853
5859
Reserved
5854
ACM2 Zone Options
Door 1
ADDR
Door 2
ADDR
Door Contact 5860 5865
Forced Entry Zone 5861 5866
Door Ajar Zone
5862
5867
Area # for Door 2 5868
Reserved 5863 5869
Reserved
5864
ACM3 Zone Options
Door 1
ADDR
Door 2
ADDR
Door Contact 5870 5875
Forced Entry Zone 5871 5876
Door Ajar Zone
5872
5877
Area # for Door 2 5878
Reserved 5873 5879
Reserved
5874
ACM4 Zone Options
Door 1
ADDR
Door 2
ADDR
Door Contact 5880 5885
Forced Entry Zone 5881 5886
Door Ajar Zone
5882
5887
Area # for Door 2 5888
Reserved 5883 5889
Reserved
5884
5890
ACM Global Flags
Default
Option
OFF
1
Enable Two-Swipe Arming
OFF
2
Enable NAPCO Proprietary Access Format
OFF
3
Enable Facility Code
OFF
4
Enable Access Logging into Burg Log
OFF
5
Enable Printing of Access Events
OFF 6
Enable Card Presentation Beep and Green LED Flash
OFF 7
Enable Other Area/All Area Disarm on an Already
Disarmed Area Before Allowing Access
OFF 8
RESERVED
ACM GLOBAL FLAGS:
 1. Select the desired option entering the option number
(1-8) for each digit.
 2. Enter corresponding option number in address loca-
tion.
NOTE: Dark shaded data value box shows option not
available. Press U to save.
Enable Other Area/All Area Disarm on an Already Disarmed Area Before
Allowing Access
When enabled, this feature operates as per the following example: Area 1 is
disarmed by a credential (proximity card) with permission to disarm only Area 1.
Later, another credential with permissions to disarm Areas 1, 3 and 4 is presented
to the already disarmed Area 1. The second credential will allow access to Area
1 only, but will not disarm nor allow access to Areas 3 and 4.
ADDRESS 5892
Maximum Two
-Swipe Arm
Time
(x100ms)
[Default = 030 = 3 seconds.]
ADDRESS 5893
Unlock Time
(sec.)
[Default = 005 = 5 sec.]
Enable ACM Access (address 5328) must be enabled.
Address 5892 determines the maximum time allowed for the double swipe (x100ms). Address 5893 determines the door unlock
time, in seconds, after a successful entry.
 1. Select timeout (1-255).
 2. Enter in corresponding address locations above and right. Press U to save.
