NAPCO StarLink Fire: Getting Started Guide 13
The following summarizes the minimum required NOC programming (hƩp://NapcoNOC.com) and system wiring when connecƟng a StarLink Fire Communica-
tor to the DACT of an FACP, uƟlizing dial capture mode reporƟng. Check the installaƟon and programming instrucƟons for addiƟonal wiring and programming
opƟons. Be sure all items in the following checklist are performed:
1. Central StaƟon Receiver Telephone numbers are programmed in the "Dealer
EnteredProgramming" secƟon (see image at right):
2. UL Poll Fail Timeout is set (200 seconds NFPA 2007 service plan; 5 min. for
NFPA 2010 plan; 60 min. for NFPA 2013 plan or 24hr backup only):
3. (PGM1) is wired to a trouble zone in the FACP. Wire the control panel Listed
EOLR in series (terminal 3 PGM Output #1 and ground terminal #8) to a zone or
point programmed to monitor communicator troubles.
Installation Quick Start / Checklist for Fire Alarm Control Panel DACT Connect Operation
WI2162A 04/16
6 7 8
15 14 13 12 11
9
10
2 3 4 5 1
17 16
StarLink Terminals
(STARLINK HOUSING)
All connections are power limited except AC Mains,
Telco and battery terminals.
Terminals 14-17: No connections permitted.
RED
GREEN
9LE10KHARN installed in FACP:
Blue/Red normally closed relay open on trouble
Red/Black normally open relay short on alarm
To FACP Ground /
Common Terminal
(not earth ground)
To panel Telco if using
DACT reporting
+V
(12/24V)
(–) PGM1 PGM2 PGM3 IN1 IN2 GND IN3 RING TIP
RTS
(R)
PANEL
TX (B)
PANEL
RX (G)
CTS
Y
PANEL
RING (+)
PANEL
TIP (–)
(Use FACP Listed
EOLR)
To FACP conventional
zone positive terminal
programmed for
communicator trouble
See
Note 3
If using addressable input for
communicator supervision,
connect Form C relay as
shown below.
– +
EOLR
EOLR
C
N/C
N/O
See
Note 4
2
1
Note: All wiring diagrams and programming depicted in this guide assume the wiring between the radio and the FACP is protected by conduit.
Notes:
1. For NAPCO control panel downloading or remoteupgradingofradi ofirmw are, radio jumper X5_J1 must be removed.
2. Upon acƟvaƟon of the fire trouble relay (open between blue and red harness wires), a fire trouble signal will be transmiƩed to the central staƟon.
3. For StarLink models SLECDMA-CFB-PS and SLE3/4G-CFB-PS, connect to charger board terminal labeled N/ O.
4. If using external relay for radio supervision, relay must be rated for radio input voltage, (12VDC, max current draw=50mA OR 24VDC, max current
draw=25mA). A listed low current relay, such as Space Age Electronics model SSU-MR-311/C/R is recommended.
To Next Page
