NAPCO StarLink Fire: Getting Started Guide 25
Reconnect the Ethernet cable:
IP Cable and Antenna Signal Loss Test
Remove both the Ethernet cable and antenna, then observe the following indications:
Reconnect both the Ethernet cable and antenna:
Red Trouble LED DS16 Turns off.
Yellow Trouble LED DS15 Slow blink.
Trouble Relay Output on
SLEULPS-R Trouble LED
Turns off.
Supervisory restore signal R788 (zone 2) will be received by the cen-
tral station within 24 hours of the Ethernet cable being reconnected.
Green IP Network LED DS14 1 Blink (Static IP) or 2 Blinks (DHCP)
Red Trouble LED DS16 Turns off.
Yellow Trouble LED DS15 Slow blink.
Trouble Relay Output on
SLEULPS-R Trouble LED
Turns off.
Supervisory restore signal R356 will be received by the central station
within 24 hours of the Ethernet cable and antenna being reconnected.
Green IP Network LED DS14 1 Blink (Static IP) or 2 Blinks (DHCP)
Red Trouble LED D5 Turns off.
LED Verify this Condition Passed?
Red Trouble LED DS16 Blinks 1 time every 4 seconds.
Yellow Trouble LED DS15 on
SLE-ULPS-R
Remains on solid.
Trouble Relay Output on
SLEULPS-R Trouble LED
Blinks 4 times.
Supervisory signal E356 will be received by the central station within
24 hours of the Ethernet cable and antenna being removed.
Green IP Network LED DS14 Turns off.
Red Trouble LED D5 Blinks 5 times.
To Next Page
