28 NAPCO StarLink Fire: Getting Started Guide
Reconnect the radio battery:
Signal Loss Test
This test ensures that the SLECDMAI-CFB-PS or SLE3/4GI-CFB-PS will indicate a supervisory trouble condition to
the FACP and central station upon loss of signal within the required time.
Remove the antenna and observe the following indications:
Reconnect the antenna:
Note: In cases where the radio may be located in close proximity to the cell tower, there is a possibility that the
radio may operate properly, even with the antenna removed.
IP Signal Loss Test
This test ensures that the SLECDMAI-CFB-PS or SLE3/4GI-CFB-PS will indicate a supervisory trouble condition to
the FACP and central station upon loss of signal within the required time period.
Remove the Ethernet cable and observe the following indications:
(continued)
Yellow Trouble LED Turns off.
Trouble Relay Output Restores; check for proper trouble restoral at FACP.
LED Verify this Condition Passed?
Red Trouble LED D5 Blinks 5 times.
Trouble Relay Output on
SLEULPS-R Trouble LED
Blinks 4 times.
Supervisory signal E788 (zone 1) will be received by the central station
within 6 hours of the antenna being removed.
Red Trouble LED D5 Turns off.
Trouble Relay Output on
SLEULPS-R Trouble LED
Turns off.
Supervisory restore signal R788 (zone 1) will be received by the cen-
tral station within 6 hours of the antenna being reconnected.
LED Verify this Condition Passed?
Red Trouble LED DS16 Blinks 1 time every 4 seconds.
Yellow Trouble LED DS15 Remains on solid.
Trouble Relay Output on
SLEULPS-R Trouble LED
Blinks 4 times.
Supervisory signal E788 (zone 2) will be received by the central station
within 6 hours of the Ethernet cable being removed.
Green IP Network LED DS14 Turns off.
