W415-0341 / K / 10.05.07
PG 3-5 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
Dimensions
5-14 VENTING
Venting Lengths
Air Terminal Locations
Venting Application Flow Chart
Venting Specifications
15-24 INSTALLATION
Wall & Ceiling Protection
Using Flexible Vent Components
Using Rigid Vent Components
Restricting Vertical Vents
Mobile Home Installation
Gas Installation
Framing
Nailing Tab Installation
Mantle Clearances & Enclosures
25-27 FINISHING
Log Placement
Door Removal & Installation
Logo Placement
Louvre Removal & Installation
28 OPTIONAL BLOWER
29-30 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
30 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustment
31-33 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Accessories
Vent Kits
Terminal Kits
34-35 TROUBLE SHOOTING GUIDE
36 NOTES
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
WARNING
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay awa
to avoid burns or clothing ignition. Supervise young children when they are in the same room as the fireplace.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the fireplace is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from ho
surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fireplac
and venting system are kept clean. The fireplace and its venting system should be inspected before use and at leas
annually by a qualified service person. More frequent cleaning may be required due to excessive lint from carpeting
bedding material, etc. The fireplace area must be kept clear and free from combustible materials, gasoline an
other flammable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service technician to inspec
the fireplace and to replace any part of the control system and any gas control which has been under water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass should b
done by a licensed or qualified service person.
• Do not strike or slam shut the fireplace glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple supplie
by Wolf Steel Ltd.
• Pressure relief doors must be kept closed while the fireplace is operating to prevent exhaust fumes containin
carbon monoxide, from entering into the home. Temperatures of the exhaust escaping through these openings ca
also cause the surrounding combustible materials to overheat and catch fire.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
