Napoleon PRO285 - Parts List

17
www.napoleon.com
N415-0309-AU JUL 18.19
Parts List
x - standard ac - accessoires
p - propane only n - natural only
Item Part # Descripon
1 N135-0045NH-BK1HT base x
2 N010-0830 drip pan plate x
3 N570-0104 screw, 10-24 X 3/8” x
4 N475-0319 control panel x
5 N010-0773 manifold x
6 N570-0078 screw, m4 x 8mm x
7 N585-0089-BK1HT control panel heat shield x
8 N570-0076 screw, #8 X 1/2” x
9 N380-0020-RD control knob x
10 N570-0073 screw 1/4-20 x 3/8” x
11 N710-0079 drip pan x
12 Z570-0033 screw, 10-24 x 12mm x
13 N100-0047 burner, right x
14 N100-0046 burner, le x
15 N325-0083 lid handle x
16 N655-0179 lid handle support le x
17 N655-0180 lid handle support right x
18 N685-0017 temperature gauge x
19 N570-0107 screw, 10-24 x 30mm x
20 N135-0048-BK1HG lid x
21 N485-0023 clevis pin x
22 N485-0021 coer pin x
23 N080-0302 cross light bracket x
24 N305-0087-BK2FL cooking grid le x
25 N305-0088-BK2FL cooking grid right x
26 N080-0303 bracket, leg x
27 N160-0025 clip x
28 N570-0068 screw, #14 x 1/2” x
29 N080-0346-BK1SG bracket, ex line x
30 N160-0029-BK1SG bracket, regulator x
31 N255-0057 ng x
32 W450-0027 nut, 1/2-20 x
33 N530-0048 regulator x
34 N075-0091 craddle front x
35 N325-0088 craddle handle x
36 N325-0089 craddle handle cover x
37 N510-0013 silicone bumper x
38 N720-0060 manifold ex x
39 N135-0048-BKIHG-SER assembly, lid x
40 N475-0319-SER assembly, control panel x
41 N010-0834 assembly, craddle x
42 N325-0083-SER assembly, lid handle x
61288 cover - grill head only ac
61287 cover - for PRO285 - stand ac
56080 griddle ac
PRO285-STAND-AU oponal cart and shelves for PRO285 ac
