Annex 1– LCD Menu Instruction (Optional)
Press “MENU” to enter the following interface
Welcome
Battery manage system
-------------------------
Press “MENU” next
Press “MENU” to enter the following interface
Battery parameters query
Battery status Battery
parameter settings Version
Information
1. The “Battery Parameters” subdirectory
——Voltage: xxxx V
——Current: xxxx A (charge: +, discharge: -)
2. The “Battery Temperature” Subdirectory
——Temperature01: xx℃
——Temperature02: xx℃
——Temperature03: xx℃
——Temperature04: xx℃
——PCB Temperature: xx℃
——Environment Temperature: xx℃
——The “Cell Voltages” Subdirectory
——Cell01: xxxx mV
——Cell02: xxxx mV
——Cell03: xxxx mV
——Cell04: xxxx mV
——Cell05: xxxx mV
——Cell06: xxxx mV
——Cell07: xxxx mV
——Cell08: xxxx mV
——Cell09: xxxx mV
——Cell10: xxxx mV
——Cell11: xxxx mV
——Cell12: xxxx mV
——Cell13: xxxx mV
——Cell14: xxxx mV
——Cell15: xxxx mV
——Cell16: xxxx mV
——SOC: xxxx%
——Nominal Capacity: xxxx Ah
——Remaining Capacity: xxxx Ah
——Battery Cycles: xxxx
The “Battery Status” Subdirectory
——Status: IDLE/CHARGE/DISCHARGE
