Page 6
2 Equipment description
The Narcotrend consists of the following components:
• Narcotrend-Compact M
• Narcotrend-Compact M - power supply
• Patient lead 1-channel (PKM1)
• Patient lead 2-channel (PKM4) (optional)
• Mounting clamp (optional)
• Use only the original Narcotrend-Compact M - power supply.
Fig. 2: Narcotrend-Compact M, front panel
On/Off switch
Interface for
patient lead
Touchscreen
