Narvon 378SM261 - Cleaning and Disassembly Guide; Emptying and Disassembling Components

NARVON
5
CLEANING
EMPTY THE BOWL(Skipthisstepifthisistheinialcleaning)
DISASSEMBLY
Dispensing Tap(Fig.6)
Lid(Fig.7)
Bowl(Fig.8-12)
Drip Tray (Fig.13)
1. Usethetaplevertoemptyanyremainingliquidintoacontainer.
2. DO NOT proceed without emptying the bowl.
1. Place hand beneath the dispensing outlet
to catch pieces as they are released.
2. PulltheLeverPin(A)todisconnectthe
TapValve(C)andSpring(D).
3. IftheTapLever(E)istobewashed,
removeLeverPin(B).
1. Lithelidstraightupwardto
remove from the bowl.
1. Removethe(2)FrontFixingKnobsbyunscrewingthem
counter-clockwise.(Fig.8)
2. Remove the bowl from its seat. (Fig.9)
3. Gently pull on the spiral blades to remove from the cylindrical
evaporators.(Fig.10)
4. GentlypullontheSpiralBladeGaskettoremove.(Fig.11)
5. Gently pull on the Bowl Gasket to remove. (Fig.12)
1. Liupwardandthenawayfromthemachinetounseatthehooks.
2. Wash with warm water and dry.
3. Re-insert the hooks into their holes and push down.
The machine must be turned OFF and unplugged
from the power source before cleaning.
CAUTION
CAUTION
I
I
0
0
Fig. 7
Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 13
When cleaning
orliing,
DO NOT GRAB
THE MACHINE
BY THE
CYLINDRICAL
EVAPORATORS.
Fig. 6
AB
C
D
E
