NARVON
7
Allwashedand/orsanizedpartsmustbecompletelydrybeforebeing
carefully reassembled. Some components must be lubricated in order to
workeciently.Atubeoflubeisincludedwitheachmachine.
Fig. 16
Fig. 17
Fig. 19
Fig. 18
Fig. 20
Fig. 21
Fig. 22
CAUTION
When cleaning
orliing,
DO NOT GRAB
THE MACHINE
BY THE
CYLINDRICAL
EVAPORATORS.
REASSEMBLY
Bowl(Fig.16-20)
Lid(Fig.21)
Dispensing Tap(Fig.22)
1. PlacetheBowlGasketattheboomoftheCylinder
Evaporator,lubricangtheupperpart(A).(Fig.16)
2. Lubricatethesurfaceofthecylinderinthezoneof
thetransmissionshaoutlet(A).(Fig.17)
3. PlacetheSpiralBladeGasket(B),lubricangboththe
internalandexternalsurfaces.(Fig.17)
4. InserttheSpiralBladesothattheheadjoinsthe
transmissionsha.(Fig.18)
5. LubricatetheexternalpartoftheheadoftheSpiral
Blade(A).(Fig.18)
6. Aerallbowlcomponentsareproperlyposioned
andlubricated,slidetheBowlintoposion.(Fig.19)
7. SecurethebowlbyscrewingtheBowlFixingKnobs
clockwise.(Fig.20)
1. Placethelidoverthebowl,verifyingthecorrect
inseronoftheelectriccontacts.
1. PlacetheLever(E)inplacesoPin(B)linesup
correctly.InsertPin(B)andsecure.
2. LubricatetheTapValve(C).
3. InserttheSpring(D)intotheproductsupplyhole,
followedbythelubricatedTapValve(C)andsecure
withPin(A).
A
A
A
B
C
D
E
