End user communication language
single phase (V209, 214)
asynchronous three-phase
synchronous PM (permanent magnets)
Rated current of the motor per it’s nameplate indication increased
by 10%. The voltage drop caused by the inverter leads to higher
input current than nominal. Make sure motor is capable of
accepting increased current.
Rated frequency of the motor per its nameplate.
Control mode: Constant value [bar]
If the transducer is not connected or connected improperly, the
signal SENSOR OFF is activated when pressing ENTER.
Maximum pressure allowed in the system. If the pressure goes over
this value, an alarm occurs and the pump is stopped. Pump is
automatically restarted if the pressure goes below the maximum
value for a period of at least 5 seconds.
The pressure value to be kept constant.
If the device is "FOC-ready", motor calibration must be carried out
before commissioning.
Carefully read the pertinent chapter.
Press START/STOP to run a test at rated frequency
Warning: make sure to run the system without damaging pump
and system
If, during the test, the motor runs in reverse, it is possible to change
the wiring sequence via software without physically changing wires
at the terminals.
Activation or deactivation of COMBO operation.
If ON is selected, after a lack of voltage, the inverter returns to its
normal status; if the unit was powering the pump before the voltage
drop, it resumes powering the pump automatically.
Warning, review the advice in chapter 1
Rated motor Amp.
I = XX.X [A]
Rated motor freq
f = XXX [Hz]
F. scale sensor
p = XX.X [bar]
Max alarm value
p = XX.X [bar]
Rotation sense
---> / <---
To Next Page
