3. Technical Characteristics
Model
Vin +/- 15% [V]
Max V out
[V]
Max I in
[A]
Max I out
[A]
P2 motor
power*
[kW]
Size
V209
1 x 230
1 x Vin
15
9
1,1
1
3 x Vin
7
1,5
1
V214
1 x 230
1 x Vin
20
9
1,1
1
3 x Vin
11
3
1
V218
1 x 230
3 x Vin
38
18
4
2
V225
1 x 230
3 x Vin
53
25
5,5
2
V230
1 x 230
3 x Vin
63
30
7,5
3
V238
1 x 230
3 x Vin
80
38
9,3
3
V306
3 x 230
3 x Vin
10
6
1,1
1
V309
3 x 230
3 x Vin
13,5
9
2,2
1
V314
3 x 230
3 x Vin
13,5
14
3
2
V318
3 x 230
3 x Vin
17,5
18
4
2
V325
3 x 230
3 x Vin
24
25
5,5
2
V330
3 x 230
3 x Vin
29
30
7,5
2
V338
3 x 230
3 x Vin
42
38
9,2
3
V348
3 x 230
3 x Vin
52
48
11
3
V365
3 x 230
3 x Vin
68
65
15
3
V375
3 x 230
3 x Vin
78
75
18,5
3
V385
3 x 230
3 x Vin
88
85
22
3
V406
3 x 380 - 460
3 x Vin
10
6
2,2
1
V409
3 x 380 - 460
3 x Vin
13,5
9
4
1
V414
3 x 380 - 460
3 x Vin
13,5
14
5,5
2
V418
3 x 380 - 460
3 x Vin
17,5
18
7,5
2
V425
3 x 380 - 460
3 x Vin
24
25
11
2
V430
3 x 380 - 460
3 x Vin
29
30
15
2
V438
3 x 380 - 460
3 x Vin
42
38
18,5
3
V448
3 x 380 - 460
3 x Vin
52
48
22
3
V465
3 x 380 - 460
3 x Vin
68
65
30
3
V475
3 x 380 - 460
3 x Vin
78
75
37
3
V485
3 x 380 - 460
3 x Vin
88
85
45
3
 Power frequency: 50 - 60 Hz (+/- 2%)
 Max. ambient temperature at nominal current: 40°C (104 °F)
 Max. altitude at nominal current: 1000 m
 Grade of protection: IP55 (SIZE 1,2) , IP54 (SIZE 3) *
 RS485 serial communication
* auxiliary cooling fan, used in wall mounted applications, has a protection rating of IP54.
The inverter is able to power the motor with a higher current for a short period of time according to the linear
relation: 101% of the nominal current for 10min., 110% nominal current for 1 min.
