BNC-2110 Installation Guide 8 ni.com
Specifications
This section lists the specifications of the BNC-2110. These specifications
are typical at 25 °C unless otherwise specified.
Physical
Dimensions .............................................19.05 by 10.48 by 3.51 cm
(7.5 by 4.125 by 1.38 in.)
I/O connector ..........................................68-pin male connector
Environment
Operating temperature ............................0 to 70 °C
Storage temperature................................–55 to 125 °C
+5 V +5 V power—These pins are fused on the DAQ device and
are self-resetting; the current available depends on the
product to which it is connected
P0.<7..0> Digital input/output lines 7 through 0—P0.6 and 7 can
control the up/down signal of General-Purpose Counters 0
and 1, respectively
CTR 1 OUT Counter 1 Output—This is the output from
General-Purpose Counter 1
USER 1 User-defined 1—Connected to USER 1 BNC, this terminal
provides a user-definable BNC signal
AI HOLD AI Hold Complete—This pin pulses once for each
A/D conversion when enabled
EXSTRB
*
External Strobe—This signal controls external devices
under control of NI-DAQ
AI SENSE
1
Analog Input Sense—This pin serves as the reference node
for channels AI <0..15> in NRSE configurations
AI GND
2
Analog Input Ground—The analog input voltages are
referenced to this node
* Indicates active low
1
Refer to your DAQ device user manual for more information on using this signal.
2
E Series and S Series devices only
Table 4. BNC-2110 Digital Terminal Descriptions (Continued)
Terminal Description
