BNC-2111 Installation Guide 2 ni.com
Figure 1. BNC-2111 Front Panel (Shown with Metal Enclosure)
1 Floating Source (RSE)/
Ground-Referenced Source (NRSE) Switch
2 BNC Connectors
3 BNC Center Pin
4 BNC Shield
AI GND
AI SENSE
AI0
AI6
AI12
AI1
AI7
AI13
AI2
AI8
AI14
AI3
AI9
AI15
AI4
AI10
AO0
AI5
AI11
AO1
APFI 0/
(AO EXT REF)
BNC-2111
2
3
PFI 13/P1.0
(CTR 1 OUT)
PFI 12/P2.4
(CTR O OUT)
PFI 7/P1.7
(PFI 7/AI SAMP)
PFI 2/P1.2
(PFI 2/AI CONVERT)
4
NRSE
RSE
AIx
M SERIES (E SERIES)
1
PFI 0/P1.0
(PFI 0/AI START)
