National Instruments cRIO-9039 User Manual

Table 4. STATUS LED Indicators
LED
Color
LED Pattern Indication
Yellow Blinks twice and
pauses
The cRIO-9039 is in safe mode. Software is not installed,
which is the factory default state, or software has been
improperly installed on the cRIO-9039.
An error can occur when an attempt to upgrade the software
is interrupted. Reinstall software on the cRIO-9039. Refer
to the Measurement & Automation Explorer (MAX) Help for
information about installing software on the cRIO-9039.
Blinks three times
and pauses
The cRIO-9039 is in user-directed safe mode, or the
cRIO-9039 is in install mode to indicate that software is
currently being installed.
This pattern may also indicate that the user has forced the
cRIO-9039 to boot into safe mode by pressing the reset
button for longer than five seconds or by enabling safe
mode in MAX. Refer to the Measurement & Automation
Explorer (MAX) Help for information about safe mode.
Blinks four times
and pauses
The cRIO-9039 is in safe mode. The software has crashed
twice without rebooting or cycling power between crashes.
Continuously
blinks
The cRIO-9039 has not booted into NI Linux Real-Time.
The cRIO-9039 either booted into an unsupported operating
system, was interrupted during the boot process, or detected
an unrecoverable software error.
On momentarily The cRIO-9039 is booting. No action required.
Red Continuously
blinks
This indicates a hardware error. An internal power supply
has failed. Check front-panel I/O and C Series module
connections for shorts. Remove any shorts and cycle power
the cRIO-9039. If the problem persists, contact NI.
— Off The cRIO-9039 is in run mode. Software is installed and the
operating system is running.
NI cRIO-9039 Getting Started Guide | © National Instruments | 15
