National Instruments GPIB-USB Series User Manual

Appendix A Specifications
© National Instruments A-5 GPIB Hardware Guide
Performance
GPIB
3-wire .............................................. Up to 1610 Kbytes/s
HS488 ............................................. Up to 7960 Kbytes/s
GPIB-ENET/100
Environment
Operating ambient temperature.............. 0 to 65 °C
Operating relative humidity ................... 10 to 90%, noncondensing
Storage ambient temperature ................. -40 to 100 °C
Storage relative humidity ....................... 5 to 95%, noncondensing
(Tested in accordance with
IEC-60068-2-1, IEC-60068-2-2,
and IEC-60068-2-56.)
Power requirements................................ External source 9 to 30 VDC
+15 VDC @ 250 mA typical,
425 mA max
Performance
GPIB
3-wire .............................................. Up to 1000 Kbytes/s
GPIB-ENET/1000
Physical
Dimensions............................................. 20.6 × 12.7 × 3.7 cm
(8.125 × 5 × 1.438 in.)
Weight.................................................... 402 g (14.2 oz)
Operating Environment
Ambient temperature range.................... 0 to 55 °C
(Tested in accordance with
IEC-60068-2-1 and
IEC-60068-2-2.)

National Instruments GPIB-USB Series Specifications

General

Bus Interface	USB
Dimensions	Varies by model
Weight	Varies by model
GPIB Standard	IEEE 488
Operating System	Linux
Compatibility	IEEE 488.1 and IEEE 488.2
Power Supply	Powered via USB
