Design Guide on ni.com/manuals for more information about how to power the NI sbRIO
device through the RMC.
Caution Exceeding the power limits may cause unpredictable device behavior.
Recommended power supply 55 W, 30 VDC maximum
Power supply voltage range 9 VDC to 30 VDC
Reversed-voltage protection 30 VDC
Power consumption with RMC 29 W maximum
Environmental
Caution Clean the sbRIO-9627 with a soft, nonmetallic brush. Make sure that the
device is completely dry and free from contaminants before returning it to service.
Local ambient operating temperature near
device (IEC 60068-2-1, IEC 60068-2-2)
-40 °C to 85 °C
10
Maximum reported onboard sensor temperature
CPU/FPGA temperature 98 °C
Primary System temperature 85 °C
Secondary System temperature 85 °C
Table 1. Component Maximum Case Temperature
Component Manufacturer Maximum Case Temperature
CPU/FPGA Xilinx NA
11
DDR memory Micron 95 °C
NAND flash Micron 89 °C
CPLD Lattice 94 °C
USB PHY Microchip 120 °C
ENET PHY Micrel 120 °C
The sbRIO-9627 includes three onboard temperature monitoring sensors to simplify validation
of a thermal solution by indicating thermal performance during validation and deployment.
10
If you expect ambient temperatures below -20 °C, NI recommends using a 10/100 network
infrastructure or assigning 10/100Mbps communication speeds to the Ethernet Adapter in NI MAX.
Refer to the Network/Ethernet Port section of this document for more information.
11
Use digital approach to ensure the on-chip temperature reading is below 98°C.
NI sbRIO-9627 Specifications | © National Instruments | 11
