Wire mode 4-wire, 2-wire, 2-wire auto
Isolation voltage, port to earth ground None
Embedded CAN
Number of interfaces
Onboard CAN 1 (CAN0)
RMC CAN via FPGA 3.3 V DIO 1 (CAN1)
Onboard CAN transceiver NXP PCA82C251T
Maximum baud rate 1 Mbps
Minimum baud rate 10 kbps
USB Port
Number of interfaces
Front Panel USB Host 1 (USB0)
RMC USB Host/Device 1 (USB1)
Compatibility USB 2.0, Hi-Speed
Maximum data rate 480 Mb/s
Maximum front panel USB current 900 mA
SD Card Slot
Number of interfaces
Front Panel SD 1 (SDIO0)
RMC SD via FPGA 3.3 V DIO 1 (SDIO1)
Supported Standards SD, SDHC
5
Front Panel SD Throughput
Read 12.0 MB/s maximum
Write 9.0 MB/s maximum
5
Both standard SD and microSD interfaces are supported.
4 | ni.com | NI sbRIO-9627 Specifications
