Output logic levels
Output high voltage, V
OH
when sourcing 3 mA
2.4 V minimum; 3.45 V maximum
Output low voltage, V
OL
when sinking 3 mA
0.0 V minimum; 0.4 V maximum
Analog Input Characteristics
Number of channels 16 single-ended or 8 differential
ADC resolution 16 bits
Maximum aggregate sampling rate 200 kS/s
Input range ±10 V, ±5 V, ±2 V, ±1 V
Maximum working voltage (signal + common mode)
10 V range ±11 V
5 V range ±10.5 V
2 V range ±9 V
1 V range ±8.5 V
Input impedance
Powered on > 1 GΩ in parallel with 100 pF
Powered off/overload 2.3 kΩ minimum
Overvoltage protection
Powered on ±25 V, for up to 2 AI pins
Powered off ±15V
AI accuracy
Measurement Conditions Range Percent of Reading (Gain
Error)
Percent of Range (Offset
Error)
Typical (25 °C, ±5 °C) 1 V 0.042% 0.007%
2 V 0.007%
5 V 0.007%
10 V 0.008%
6 | ni.com | NI sbRIO-9627 Specifications
